Summary of Contents for Seeed Grove MOSFET
- Page 1 Grove – MOSFET User Manual Release date： 2015/9/22 Version： Wiki: http://www.seeedstudio.com/wiki/Grove_-_MOSFET Bazaar:http://www.seeedstudio.com/depot/Grove-MOSFET-p- 1594.html...
-
Page 2: Document Revision History
Document Revision History Revision Date Author Description Sep 22, 2015 Jiankai.li Create file... -
Page 3: Table Of Contents
Contents Document Revision History · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 2 1. - Page 4 Under the supervision of Seeed Technology Inc., this manual has been compiled and published which covered the latest product description and specification. The content of this manual is subject to change without notice.
-
Page 5: Introduction
1. Introduction Grove – MOSFET enables you to control higher voltage project, say 15VDC, with low voltage, say 5V, on microcontroller. MOSFET is also a kind of switch, but its switching frequency can reach up to 5MHz, much faster than normal mechanical relay. There are two screw terminals on the board. -
Page 6: Specification
2. Specification Working voltage: 5V Vin: 5 ~ 15V MOSFET Model: CJQ4435... -
Page 7: Interface
3. Interface Vin: accepts 5V ~ 15V power of which current is less than 2A. Vout: attach actuators here. -
Page 8: Demonstration
4. Demonstration With Arduino Here we demonstrates how to use Grove - MOSFET to control a motor. We provide power for it with external power source, but if your controlled device needs current smaller than 300mA, Seeeduino can totally support it and no extra power source needed. // demo of Grove - MOSFET // use pin 6 to control a motor int motorPin = 6;... -
Page 9: With Raspberry Pi
int onSpeed = 200; // a number between 0 (stopped) and 255 (full speed) int onTime = 2500; int offSpeed = 50; // a number between 0 (stopped) and 255 (full speed) int offTime = 1000; analogWrite(motorPin, onSpeed); delay(onTime); analogWrite(motorPin, offSpeed); delay(offTime);... - Page 10 # Connect the Grove MOSFET to analog port D6 # SIG,NC,VCC,GND mosfet = 6 grovepi.pinMode(mosfet,"OUTPUT") time.sleep(1) while True: try: # Full speed grovepi.analogWrite(mosfet,255) print "full speed" time.sleep(2) # Half speed grovepi.analogWrite(mosfet,128) print "half speed" time.sleep(2) # Off grovepi.analogWrite(mosfet,0) print "off"...
-
Page 11: Resource
5. Resource Grove - MOSFET Eagle File CJQ4435 Datasheet MOSFET_WIKI Getting started with Arduino ... - Page 12 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Seeed Studio 103020008...
