Summary of Contents for Genotech GWL-2400P
- Page 1 GWL-2400P ( WIRELESS LANCARD ) GENOTECH CO . LTD...
- Page 2 NOTICES This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions . 1. This device may not cause harmful interference. 2. This device mus t accept any interference received, including interference that may cause undesired operation.
- Page 3 GWL-2400P Technical Support Your comments and suggestion help us to improve the quality and usefulness of our documentation, you may response to the following contact e-mail. If you encounter problems when installing or using this product, or would like more information about our other products, you can contact us with the telephone numbers listed below.
- Page 4 Important Safety Information • Read these simple guidelines. Breaking the rules may be dangerous or illegal. GENOTECH will not be responsible for any damages caused by breaking the rules. • Wireless LAN Card described in this document is approved for use in a wireless local area network.
-
Page 5: Table Of Contents
CONTENT GENERAL 1-1 Overview of IEEE 802.11 1-2 Characteristic 1-3 Composition SPECIFICATION 2-1 General Specification 2-2 Network Specification 2-3 Environmental Specification 2-4 Physical Characteristics INSTALLATION 3-1 Installation Procedure 3-2 Uninstallation Method 3-3 Configuration utility... -
Page 6: General
1. GENERAL 1-1 Overview of IEEE 802.11 The IEEE 802.11 specification is a standard for wireless connectivity for fixed, portable, and moving stations within a local area. The IEEE 802.11 standard describes the services required by a compliant device to operate within an “ad hoc”... -
Page 7: Characteristic
• The GWL-2400P for Notebook PC is small and portable as a roaming function is provided for users who need network services while maintaining mobility. -
Page 8: Specification
2. SPECIFICATION 2-1 GENERAL SPECIFICATIONS *type : PC Card Type II *Coverage Area Open Space : Up to 350m at 2Mbps / Up to 200m at 11Mbps Office Environment : Up to 70m at 2Mbps / Up to 50m at 11Mbps *Operating voltage : 3.3V ±... -
Page 9: Environmental Specification
*Modulation Techniques : 1Mbps/BPSK, 2Mbps/QPSK, 5.5Mbps/CCK, 11Mbps/CCK *If frequency : 374MHz *If bandwidth : 17MHz *RX/TX Switching speed : 2us (Typ) *Transmit spectral mask : -30dBc at First Side Lobes *Sensitivity : Min. –80dBm at 2Mbps / Min. – 76dBm at 11Mbps *Output power : Max. -
Page 10: Installation
PC card. Also you will see the PCMCIA Card icon on the right bottom of your screen. 10) Check for the GENOTECH 11Mbps Wireless PCMCIA LAN Card by right clicking on My Computer using the mouse. Select the Device manager... -
Page 11: Uninstallation Method
Start at the left bottom of your screen. Select the Programs. Click on the GENOTECH and click on Uninstall. Confirm message about removing the “ GENOTECH uninstall” and all of its components appear. Click on Yes. UnistallShield removes the software “ GENOTECH uninstall” successfully. Click... -
Page 12: Configuration Utility
on OK to finish the uninstall procedure. 3-3 Configuration utility during the installation of your GE NOTECH Wireless LAN Card, configuration utility is also installed. You can see the icon at the right bottom of your screen. Double clicking on that icon will show you the screen as shown below. State : State explains whether the client is connected to ESS or not. - Page 13 You can change the configuration by clicking on the Configuration Change. When you click on the Configuration Change, you see the screen given below. Configuration Change screen allows you to set the parameters as explained below. Mode : You can set the Network Mode to Infrastructure or Ad-hoc. SSID : The SSID can be changed to any value.
- Page 14 Network Mode, changing the channel number is of no concern as the channel is scanned automatically. Please see the table for the requirements of different countries and the channel frequency. After changing the settings in the Configuration Change Dialog box, click on Apply Changes.
- Page 15 by entering any text in the Passphrase. And click on Generate. It will generate four WEP keys Key 1, Key 2, Key 3, and Key 4. you can select any key for the security. If you do not select any Key, Key 1 is selected, as it is default key. Then click on Write and it will update the registry and driver.
