Summary of Contents for iPatrol Appbot RILEY
- Page 1 Appbot RILEY APPBOT Riley User Manual IN THE BOX Appbot RILEY Charging Station Adapter USB Cable Manual [Caution] Be sure to use the supplied adapter and cable.
-
Page 2: Install Application
1) Install Application ▶ Search and install the “Appbot Riley” from the Google “Play Store” or Apple “App Store” on your smartphone. < Installable OS version> • Google Android: 4.3 or later • Apple iOS: 8.0 or later • Not supported on PC or laptop 2) Reset the Riley ▶ Press the POWER RESET buttons at the same time for more than 3 seconds and release... - Page 3 3) Connecting the Riley ▶ Enter the Wi-Fi settings in your smartphone and choose “APPBOT-XXXXXX” from available Wi-Fi source. (Default password is “ ”) 11112222 11112222 4) Application Execution ▶ Enter “Appbot Riley” App on your smartphone. Useful Tips • If the following screen appears, the Appbot Riley is not connected. Please start again from step 3. • If the following screen is displayed continuously, please contact to Riley website global.varram.com.
- Page 4 5) Connecting to Home Wi-Fi ▶ Select your wireless router and press “OK.” Please enter the password of the wireless router. Useful Tips • When you enter WiFi password, be sure to enter small and capital letters respecively. • When password is not set on the router, click OK button. Robot LED status while connecting to the internet Connect with router Connect with internet Connect with server Successfully connected 6) Enter the Riley Password ▶...
-
Page 5: Warnings And Cautions
Register Multiple Devices How to register multiple smartphones to one Riley? • Unlimited robots can be registered to one smartphone. Please follow steps 1 through 6 for each registration. • The installation location should be same. (The home wireless router should not be changed.) • Two people cannot connect to the Riley at the same time. • Unlimited numbers of the smartphones are available to connect to one Riley. Warnings and Cautions Warning • This product is not an anti-theft or fire-alarm device. • This product should be installed by an adult. • Please carefully read all instructions in this manual before using, and observe the operation instructions and warnings shown in this manual and the product. • Please install the power cord carefully to the place out of reach of children. -
Page 6: Battery Status
Application Function Description Motion Detection Video Indicator Display when the motion detection video is recorded Battery Status Display the battery status and charge status of the robot Video Quality Setting Change the image quality Application Information Get app and robot info Face Detection Face detection function Change Password Change robot's password Motion Detection Enable motion detection Motion Detection Video Storage Check the recorded motion detection videos... -
Page 7: Video Recording
Open and close the menu window IR Night Vision ON/OFF IR Night Vision ON/OFF Joystick ON / OFF Joystick ON / OFF Automatic Stand Up Automatic return function when falling forward/backward Two-way Audio ON / OFF Two-way conversations Automatic Docking Automatic docking/undocking function Body Joystick Control Joystick controlling robot's body Send voice to appbot RILEY... - Page 8 Detailed Function Explanation ■ Joystick/Password Setting ▶ Y ou can adjust the speed by moving the joystick while pressing it. Speed adjustable Tip! High-speed Medium-speed Low-speed Going Forward Head Up Turn Right Turn Left Going Backward Head Down ■ Change Password Useful Tips * Please change Riley's password by clicking lock-button, for your security. * When you reset the robot, the password initialized to " 1234 ". * When one of the user changes the password, all of the users’...
- Page 9 ■ Motion Detection On/Off Motion Detection OFF Motion Detection ON Useful Tips * Motion detection will only work if you exit the application. * When performing motion detection at night, motion detection must be executed after turn on the night vision function. * If there is an obstacle within 3 ft, motion detection message may appear even if there is no motion. If you set the pop-up block on the mobile phone, the motion detection message will not send to you. Only the latest connector will receive the alarm message. Please be reminded that motion detection will remain ON until the button is pressed again. Click the alarm message on your smartphone to view video of detected motion. ■ Motion Detection Video Storage Motion detection video storage Motion detection video indicator icon Useful Tips * Riley stores up to 5 videos, each of 10 seconds length.
- Page 10 ■ Automatic Stand up Useful Tips * If the obstacles are nearby the Riley, it may fail to stand up automatically. * In this case, you can move forward or backward with fall off and re-execute the function. * Riley cannot get up if they fall off sideways. ■ 2 -Way Audio Communication Two-way A udio O N Two-way Audio OFF Icon to press when speaking Voice transmission progress icon Useful Tips * Please press “(Speaker shape button )” to speak through Riley. * When the Riley is too close with the connected phone, howling may occur. * If the smartphone volume is turned off, the sound will be lost. Thank you. * Appbot is a compound word made up of application + robot and is purely produced in Korea.
- Page 11 AppBot Wi-Fi CONTROLLED ROBOT THROUGHT INTERNET This equipment complies with the FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and any part of your body.
