Contents Getting started................1 Unpacking ................2 Power ..................... 4 Power options ................5 Installing the main battery ............6 Determining main battery condition.......... 6 Low power management............6 When the main battery becomes low........7 Charging the main battery..........7 Swapping the main battery.......... - Page 5 Introduction Melard Technologies’ Sidearm All-Terrain Handheld PC™ is a rugged, Microsoft Windows CE-based handheld computer with integrated wireless communications. It provides a compact and lightweight mobile computing platform for field service operations. System Features 640 x 240 touch-sensitive transflective display that supports navigation with stylus (included) or finger.
-
Page 6: Getting Started
Getting started Getting started Sidearm All-Terrain Handheld PC™ User’s Guide... -
Page 7: Unpacking
Note: If the container shows any signs of damage, contact the carrier immediately. 2. Open the box and remove the components. 3. Assure all the components you ordered are included. Note: If any items are missing, please contact Melard Customer Support at (800) MELARD4 [1-800-635- 2734]. ü ü... - Page 8 The Sidearm is not waterproof in that it cannot be immersed in liquid. Keep the original packaging in case the Sidearm needs to be transported or shipped to Melard for service. DO use the supplied stylus or equivalent to utilize the Sidearm’s touch screen feature. Use of ballpoint pens, pencils and other sharp objects will cause permanent damage to the unit’s touch screen.
-
Page 9: Power
Power for the Sidearm Power User’s Guide Sidearm All-Terrain Handheld PC™... -
Page 10: Power Options
Replace batteries ONLY with the same type. Failure to replace with the same type may result in explosion. Replacement batteries are available from Melard Technologies. Follow manufacturer’s directions for disposing of used batteries. (See page 20) NEVER burn batteries. -
Page 11: Installing The Main Battery
For this reason, it’s a good idea to keep a charged main battery in the unit at all times. User’s Guide Sidearm All-Terrain Handheld PC™... -
Page 12: When The Main Battery Becomes Low
2. Plug the AC adapter into an electrical outlet. Note: When the battery is depleted, it takes about 2 hours to fully recharge. 3. Monitor the Power LED: Orange => battery is charging. Power LED Sidearm All-Terrain Handheld PC™ User’s Guide... -
Page 13: Swapping The Main Battery
AC adapter, the internal backup battery will maintain data for a short period of time while swapping the main battery. However, the backup battery does not provide enough power to operate the Sidearm. User’s Guide Sidearm All-Terrain Handheld PC™... -
Page 14: When The Backup Battery Becomes Low
Remove backup battery door. Backup Battery Door b. Slide the battery out. 6. Insert the new backup battery: a. Slide the battery into the backup battery slot. b. Replace the backup battery door. Sidearm All-Terrain Handheld PC™ User’s Guide... -
Page 15: Using The Sidearm
10 Using the Sidearm Using the Sidearm User’s Guide Sidearm All-Terrain Handheld PC™... -
Page 16: Turning The Sidearm On And Off
Sidearm automatically turns off. Here’s how to set the power-off time: 1. Open the Control Panel ( Start / Settings / Control Panel 2. Double-tap the Power icon. 3. Tap the Power Off tab. 4. Select a power-off time. Sidearm All-Terrain Handheld PC™ User’s Guide... -
Page 17: Understanding The Indicators
Blinking green Custom use by applications. All other Custom use by applications. Note: Power lights are not active when the Sidearm is operating on battery power. Note: Wireless modem indicators may vary depending on network. User’s Guide Sidearm All-Terrain Handheld PC™... -
Page 18: Using The Stylus
The stylus is stored along the edge below the keyboard. To remove the stylus, simply snap it out of this location. Stylus Tip: To prevent loss of the stylus, always return it to its storage location when it is not in use. Sidearm All-Terrain Handheld PC™ User’s Guide... -
Page 19: Calibrating The Touchscreen
Adjusting contrast With Sidearm power on: To increase panel contrast: Press and hold the key, SHIFT then press the key. To decrease panel contrast: Press and hold the SHIFT key, then press the key. User’s Guide Sidearm All-Terrain Handheld PC™... -
Page 20: Controlling Backlighting
Setting audio volume With Sidearm power on: To increase audio volume: Press and hold the key, SHIFT then press the key. To decrease audio volume: Press and hold the key, SHIFT then press the key. Sidearm All-Terrain Handheld PC™ User’s Guide... -
Page 21: Wireless Communications (Optional)
After installing new software. If the operating system doesn’t respond. If you can’t turn on the Sidearm using the power button. Two methods for resetting are provided. Use the method appropriate for the condition you encounter: User’s Guide Sidearm All-Terrain Handheld PC™... -
Page 22: Performing A Soft Reset
1. Locate the reset button (small hole to the right of the power button). 2. Press and hold the button BACKLIGHT 3. Using the stylus, press the reset button. Sidearm All-Terrain Handheld PC™ User’s Guide... -
Page 23: Restoring Unit Back To Factory Settings
1. Disconnect AC power if applied. 2. Remove main battery and backup battery for about one minute. 3. Replace main battery. 4. Replace backup battery. User’s Guide Sidearm All-Terrain Handheld PC™... -
Page 24: Maintaining The Sidearm
Maintaining the Sidearm 19 Maintaining the Sidearm Sidearm All-Terrain Handheld PC™ User’s Guide... -
Page 25: Cleaning The Sidearm
Check with your local government offices for information on where to recycle or dispose of old batteries. If you cannot locate this information contact Melard Technologies Customer Support for assistance. User’s Guide... -
Page 26: Customer Support
Note: If you are a corporate user, your company may have its own policies regarding troubleshooting and reporting. In that case, please follow your company’s instructions. If you need to call Melard, please have the following information available: Sidearm and its major peripherals. Serial Number of your Sidearm. - Page 27 22 Maintaining the Sidearm Before returning your system to Melard, back up your files by copying to a host PC or to a PC Card. Pack your Sidearm in its original shipping container or in a sturdy corrugated box. Cushion it with bubble-wrap or foam material.
-
Page 28: Sidearm Specifications
Sidearm specifications 23 Sidearm specifications Sidearm All-Terrain Handheld PC™ User’s Guide... - Page 29 -40°C (-22°F) to 70°C (158°F) Industry approvals UL/CSA FCC Part 15 Class B Applicable International approvals Accessories (included) AC adapter Rechargeable Li-ion battery Hand strap Stylus User manual Options Docking station (AC/DC vehicle mountable) Holster/Case User’s Guide Sidearm All-Terrain Handheld PC™...
-
Page 30: Limited One-Year Warranty - Hardware
Melard's product service facility. To request warranty service, customer must call Melard's Customer Technical Support within the warranty period. If warranty service is required, Melard will issue a Return Material Authorization (RMA) Number. An RMA number is valid for 15 days from the date it was issued. - Page 31 26 Warranty Melard uses new and reconditioned parts made by various manufacturers in performing warranty repairs and building replacement products. All repairs or replacements are warranted for ninety (90) days from the date of repair or the remainder of the original warranty.
