Summary of Contents for Cellular PB2463R1
- Page 1 Cellular XF Plug-in Modem Evaluation Board User Guide Bulletin JA20-UM-Eval-Bd Revision Date 12 Dec 2017...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS and DISCLAIMER ......................2 1. INTRODUCTION ............................... 3 Scope Audience Contact Information, Support Text Conversions Related Documents Document History 2. Overview ................................4 XF Plug-In PIN-OUT Mechanical Dimension / Weight Temperature Range RoHS Compliance 3. -
Page 3: Introduction
Tip or Information – Provides advice and suggestions that may be useful when using this product. Related Documents Embedded Cellular XF Plug-in Modems – www.janus-rc.com/XF.html Document History Rev 00 – 12/12/2017 XF Evaluation Board User Guide JA20-XF_UM-Eval-Bd... -
Page 4: Overview
2. Overview In this document, all the basic functions of this product are explained and proper hardware solutions are suggested. The given information shall be considered as a starting point for properly evaluate and design products using XF Plug-in Modems. For further hardware details that may not be explained in this document, contact Janus technical support at info@janus-rc.com XF Plug-In PIN-OUT SIGNAL... -
Page 5: Hardware Guide
3. Hardware Guide XF Plug- In Modem Sockets Diversity Antenna SMA holder Antenna SMA holder Direct Module Power Supply Power On XF Module Jumper (Open SB1 to use) XF Module ON/OFF Switch XF Module Reset Switch UART IO Reference Voltage Terminal Posts Regulated Power Supply Input Connectors: –... -
Page 6: Uart Level Translation Interface
3. Hardware Guide continued The XF Evaluation Board has an on-board regulator which can accept 5VDC to power the on-board circuitry and the XF modem. This product has two main power supply connection options and an optional direct modem power supply: •... -
Page 7: Uart Port
Voltage applied to the USB_VBUS pin before the unit is on may keep the it from turning on correctly. Jumper Connector The J1 jumper on the XF Evaluation Board can be used to ground the ON_OFF pin of Telit based cellular modems. This will cause the unit to power on automatically when power is applied. -
Page 8: Getting Started
4. Getting Started This will take you through the initial steps required that will allow AT commands to be sent to a Telit based cellular XF Plug-In Modem. Some of the following components typically provided with XF Evaluation Kits will be required:... -
Page 9: Revision History
Cellular XF Plug-in Modem Evaluation Board User Guide Revision History Revision Revision Date Note 03/01/18 Initial release of XF Evaluation Board User Guide Division of The Connor-Winfield Corporation 2359 Diehl Road • Aurora, IL 60502 630.499.2121 • info@janus-rc.com www.janus-rc.com...
