Summary of Contents for S.R.Smith O-SERIES
- Page 1 O-SERIES 30” LIFEGUARD STAND ASSEMBLY INSTRUCTIONS CORPORATE HEADQUARTERS WESTERN SALES AND MANUFACTURING PLANT P.O. Box 400 ● 1017 SW Berg Parkway Canby, Oregon 97013 (503) 266-2231 ● Fax (503) 266-4334 www.srsmith.com ©S.R. SMITH, LLC 2004 06-341 DEC 05...
- Page 2 INTRODUCTION The O-Series 30” Lifeguard Stand is designed for use on competitive or municipal pools. Proper placement and maintenance are essential for proper use and to reduce the risk of accident or injury **IMPORTANT** Check entire box and inside all packing materials for parts. Before beginning assembly, read the instructions and identify parts using the figures and parts listed in this document.
- Page 3 INSTITUTIONAL LIFEGUARD CHAIR PARTS LIST ITEM NO. QTY. PART NO. DESCRIPTION 8-708 42" DIA. FOOTBOARD LGC-1001-1 O1 LEG ASSEMBLY 1 LGC-1001-2 O1 LEG ASSEMBLY 2 LGC-1001-3 O1 LEG ASSEMBLY 3 4-117 UPPER FRAME PLATE 20 5-143 1/4” FLAT WASHER S/S 16 5-149 1/4"...
- Page 4 ASSEMBLY INSTRUCTIONS 1. Align the four leg tubes (items 2, 3, &4) with the upper frame plate (item 5) as shown in Figure 2. Fasten the upper frame plate to the leg tubes with four 1/4"-20 x 2-1/4” carriage bolts (item 8), flat washers (item 6), lock washers (item 7), and acorn nuts (item 9).
- Page 5 4. Install the swivel/plate assembly onto the upper frame plate as shown in Figure 5. Secure it with four 1/4"-20 x 2-1/2” hex head cap screws (item 11), eight 1/4" flat washers (item 6), four 1/4" lock washers (item 7), and four 1/4"-20 acorn nuts (item 9).
- Page 6 FIGURE 8 SAFETY & MAINTENANCE INSTRUCTIONS • Periodically inspect the 30” O-Series Lifeguard Stand to assure there are no worn parts and that all hardware is properly tightened. • All stainless steel parts require periodic maintenance.
