Summary of Contents for Anymode TV SOLODIO
- Page 1 Wireless TV Audio Transceiver TV Solodio User Guide Thank you for purchasing this wireless TV Midnight Sound. Please read this User Manual carefully before using the machine.
-
Page 2: Table Of Contents
Table of Contents SAFETY TIPS ........19 COMPONENTS ........ 21 PORTS AND BUTTONS ....22 Transmitter (Tx) ........22 Receiver (Rx) ...........22 OPERATION ........23 Connecting ..........23 Charging ..........26 USING ..........27 Volume control .........27 Setting 3D-sound effect ......27 Mute ............28 Restarting ..........28 TROUBLESHOOTING ..... -
Page 3: Safety Tips
Safety Tips Be sure to comply with the following advice to prevent danger or property damage by using your TV Midnight sound as advised. Warning No compliance with the following advice may cause the risk of death or serious injuries. Be careful not to allow water, beverages or chemicals to flow into the device. - Page 4 Safety Notice Non-compliance with the advice may cause minor injuries or device damage. Do not leave the device next to an object with strong electromagnetic waves or magnetic properties. • It may cause malfunction or failures, and reduce the service life of the device. Wipe the outside of the device with a dry soft cloth and do not use benzene or alcohol for cleaning.
-
Page 5: Components
Components Audio Audio User Guide Transmitter Receiver AUX Cable Micro USB Cable tie Charging Cable (2EA) Earphone Eartips Optical cable (Rectangle / (S, L) Circle Type) (optional) Notice • Device information may change without prior notice. • The optical cable is optional, and you can buy it if required. -
Page 6: Ports And Buttons
Ports and Buttons Transmitter (Tx) Status LED Pairing button Mini(3.5Φ) stereo optical input port Micro USB port Receiver (Rx) Earphone output port Clip Sound effect setting / mute button Status LED Volume button / pairing button Power Micro USB port Reset hole... -
Page 7: Operation
Operation Connecting Use the USB cable to connect the USB port of your TV with the micro USB port of the transmitter. Use an analog or digital connection cable to connect the input port of the transmitter with the TV output port. Press the power button on the receiver to supply power. - Page 8 Connect the earphone cable with the earphone output port. • Enjoy TV sound. Notice • While power is ON, press the power button for at least 2 seconds to turn it off. Press both the pairing button of the transmitter and the paring button of the receiver (-/+) for at least 2 seconds at the same time to carry out pairing, if no sound is heard from the earphone although the USB...
- Page 9 • Replay automatically starts when pairing finishes. • Automatic connection is conducted when first pairing is completed after device connection. • Check LED colors to identify pairing. Device for State indication Red LED Transmitter blinking Pairing Fast LED between blinking receiver and alternately Receiver...
-
Page 10: Charging
Charging Connect the USB port of your PC or general adapter with the micro USB port on the receiver through the enclosed USB cable for charging. • You can charge the device by connecting the micro USB port of any charging adapter for Android smartphones with the micro USB port on the receiver. -
Page 11: Using
Using Volume control Press the + / - button to control volume. Setting 3D-sound effect Press the sound effect setting button. The 3D sound effect is then set. • It returns to the original state after the red LED blinks twice. Press the sound effect setting button again. -
Page 12: Mute
Mute Press the mute button for at least 2 seconds to mute all sounds. • The purple LED blinks every 1 second in the Mute mode. Press the mute button again for at least 2 seconds to deactivate mute. Restarting You can restart your TV Midnight Sound if the receiver does not normally operate. -
Page 13: Troubleshooting
Troubleshooting See the following troubleshooting tips before requesting AS if you think your device has any of the following problems. Contact the Customer Service if you need additional help. Difficulty Suggestions • Check if the receiver Receiver power battery is flat. Charge the is not ON. - Page 14 Difficulty Suggestions • Check if the room temperature is too low. Too low room temperature may reduce battery life. • Check if the battery is dead. The battery is dead if the battery charging time The battery is prolonged or replay rapidly goes flat.
-
Page 15: Specifications
Specifications Transmitter (TX) Receiver (RX) Audio 24bit 48KHz 24bit 48KHz process Analog Aux (3.5Φ) x 1 Earphone input/ (analog/digital output x 2 output combo) Optical (Circle Digital Type) x1 input/ (analog/digital output combo) Micro USB Micro USB (for power supply) (for charging) Communic RF 2.4Ghz... -
Page 16: Warranty
Warranty • One-year warranty • The warranty shall not apply to any defect, failure or damage caused by End-User's improper use or inadequate or improper maintenance and care. FCC Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 17 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (a) This device may not cause harmful interference, and (b) This device must accept any interference received, including interference that may cause undesired operation. (FCC Part 15.21) Caution: changes or modifications not expressly approved by the party responsible for compliance could void the...
- Page 18 MEMO...
- Page 19 MEMO...
- Page 20 5707-00001-007-0S...
- Page 21 FCC Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
