Model GIB500-12
Instruction Manual for Immersion Blender
Models GIB500-12, GIB750-14, GIB750-16, GIB750-18
For all after sales support, visit www.globefoodequip.com
For additional Technical Support call Globe at 1-866-260-0522.
This manual contains important safety instructions which
Maintain and use this manual as a reference for training.
and GIB750-22
•
Complete the Warranty Registration
•
Find an Authorized Servicer
•
View Parts Catalogs
- IMPORTANT SAFETY NOTICE -
must be strictly followed when using this equipment.
Model #:
Serial #:
Date of
Purchase:
Advertisement
Table of Contents
Summary of Contents for Globe GIB500-12
- Page 1 • Find an Authorized Servicer • View Parts Catalogs For additional Technical Support call Globe at 1-866-260-0522. - IMPORTANT SAFETY NOTICE - This manual contains important safety instructions which must be strictly followed when using this equipment. Maintain and use this manual as a reference for training.
-
Page 3: Table Of Contents
LIMITED IMMERSION BLENDER WARRANTY .................... 16 GLOBE FOOD EQUIPMENT COMPANY 2153 DRYDEN RD DAYTON, OH 45439 PHONE: 937-299-5493 TOLL FREE: 800-347-5423 FAX: 937-299-8623 E-MAIL: info@globefoodequip.com WEBSITE: www.globefoodequip.com © Globe Food Equipment Company, 2018 Printed in USA 980205 10/10/2018 Ver 0_Rev. A... -
Page 5: Attention Owners And Operators
If you have any questions, please contact Globe at 866-260-0522. Throughout the manual you will see warnings to help alert you to potential hazards and to help promote safe use of this equipment. -
Page 6: Key Components Of The Immersion Blender
KEY COMPONENTS OF THE IMMERSION BLENDER ENABLE Button Power Cord VARIABLE Speed Button ON-OFF Button Immersion Blender Warning Label Blender Tube Nut Blender Tube Protective Blade Guard Metal Blade Page 6... -
Page 7: Globe Safety Tips
BEFORE CLEANING, SERVICING, OR REMOVING ANY PARTS always turn immersion blender OFF and unplug power cord. • ALWAYS properly clean and sanitize your immersion blender. To prevent illness or death caused by the spread of food-borne pathogens. • USE ONLY PROPERLY INSTALLED GLOBE ACCESSORIES. Page 7... -
Page 8: Unpacking And Proper Grounding
2. Unpack the juice extractor immediately after receipt. If the machine is found to be damaged, save the packaging material and take pictures of damage. Contact Globe Food Equipment as soon as possible. Contact information and further details can be found at https://globefoodequip.com/support/order-return- policy.html... -
Page 9: Operating Instructions
• KEEP unit UNPLUGGED when not in use to prevent accidental start up. IMMERSION BLENDER ASSEMBLY Globe recommends that a wall mount be used to store the Figure 9-2 immersion blender when not in use. Damage to the blender tube can occur. - Page 10 OPERATING INSTRUCTIONS 6. Select the desired mixing speed by turning the VARIABLE speed knob clockwise. 7. Angle the immersion blender slightly and start to stir. Make sure to keep the blade of the blender tube off of the bottom of the pot so that food product will not be sucked up by the vortex action.
- Page 11 OPERATING INSTRUCTIONS IMMERSION WHISK ASSEMBLY Whisk 1. Unplug the immersion blender. Hole 2. Install the whisk on the immersion blender. 3. Align the two pegs on the immersion blender with the two holes on the whisk (Figure 11-1). 4. Tighten nut on whisk counterclockwise to fasten the whisk to the immersion blender (Figure 11-2).
-
Page 12: Cleaning & Sanitizing
CLEANING & SANITIZING TO AVOID SERIOUS PERSONAL INJURY: • BEFORE CLEANING, SERVICING, OR REMOVING ANY PARTS, always turn immersion blender OFF and unplug unit. • NEVER attempt to clean immersion blender while immersion blender is in operation. • DO NOT put immersion blender in the dishwasher or immerse in water. •... -
Page 13: Cleaning & Sanitizing
CLEANING & SANITIZING IMMERSION BLENDER, BLENDER TUBE & WHISK 1. Release the ON-OFF button to turn off the immersion blender (Figure 13-1). 2. Unplug the immersion blender. 3. Remove the blender tube or whisk from the immersion blender. ON-OFF 4. Turn blender tube or whisk nut clockwise to loosen the blender tube or whisk from Button the immersion blender (Figure 13-2 and Figure 13-3). -
Page 14: Troubleshooting
TROUBLESHOOTING ISSUE CAUSE SOLUTION Immersion blender stops Immersion blender is unplugged. Plug in immersion blender. Hold down working. ENABLE button and ON-OFF button to start. Immersion blender has overheated. Release ON-OFF button. Unplug immersion blender and allow the motor to cool down and the thermal safety mechanism to be reset. -
Page 15: Immersion Blender Accessories
IMMERSION BLENDER ACCESSORIES GIB500 & GIB750 ACCESSORIES Part No. Description GIBSTK12 Blender Tube 3.4"D x 12"L GIBSTK14 Blender Tube 3.4"D x 14"L GIBSTK16 Blender Tube 3.4"D x 16"L GIBSTK18 Blender Tube 3.4"D x 18"L GIBSTK20 Blender Tube 3.4"D x 20"L GIBSTK22 Blender Tube 3.4"D x 22"L GIBWSK10... -
Page 16: Limited Immersion Blender Warranty
LIMITED IMMERSION BLENDER WARRANTY Globe Food Equipment Company (“GFE”) warrants to the original purchaser of new equipment that said equipment, when installed in accordance with our instructions within North America and subjected to normal use, is free from defects in material or workmanship for a period of 1 year on parts (excludes wear/expendable parts). The labor warranty is one year from original installation or 18 months from actual shipment date, whichever date occurs first.
