Summary of Contents for Music Wrap M2
- Page 1 Product name: Music Wrap Bluetooth Portable Speaker Model Name: M2 FCC ID: PU5MCWP2014M2 What’s inside 1. Music Wrap Bluetooth Portable Speaker 2. User Manual Product overview: SIDE VIEW TOP VIEW ...
-
Page 2: Operation
Connections: 1. Bluetooth: Connect M2 to your mobile device via Bluetooth. 2. AUX: Connect M2 to your mobile device via a 3.5mm audio cable. 3. USB: Connect M2 to a power source using a micro‐USB charging cable. LED indicators: LED Color LED State Description Blinking every Searching a Bluetooth device for pairing. Blue/Red (alternate) 0.5 second Blinking every 5 Paired with a Bluetooth device. seconds Blinking every 1 No connection with a Bluetooth device. Blue second On Connected to a power source and fully charged or in a phone call. Blinking every 5 Paired with a Bluetooth device. Battery seconds capacity is low (less than 10%). Blinking every 1 No connection with a Bluetooth device. Red second Battery capacity is low (less than 10%). On Connected to a power source and currently charging. ... - Page 3 Bluetooth Function Button Press and hold for M2 will enter Bluetooth pairing NFC 5 seconds mode.You can use a Bluetooth pairing enabled device to search and find M2.If prompted for a PIN, enter : 0000 to confirm connection. Alternatively, you can use a NFC enabled device to touch M2 and create a Bluetooth connection. Charging Micro‐USB Port Plug the micro‐USB LED indicator turns red during charging cable charging. When fully charged, LED indicator turns blue. Music Function Button Press once Play current song in paired device. Play/Pause If a song is currently playing, this action will pause the song. Volume + Button A Press Increase volume.A notification tone will confirm when volume reaches the maximum level. Volume ‐ Button B Press Decrease volume.A notification tone will confirm when volume ...
-
Page 4: Safety Warning
Mute Button B Press for 3 seconds A notification tone will confirm that the microphone is muted. Aux Aux Port Plug a 3.5mm Play and control mediafrom the streaming audio cable to M2 device connected to M2 via AUX and mobile device cable. Hook Hooks Link using a cable Link the two speakers together using a cable to secure them from unnecessary movements. Safety Warning: Avoid hearing damage: ‐ Permanent hearing loss may occur if the speaker is used at high volume when it is placed near your ears. Set the volume to a safe level. ‐ Before you place the speaker on your neck, set the volume to the minimum level. After the speaker has been properly positioned on your neck, adjust the volume to a comfortable level. ‐ Turn down the volume if you can’t hear people speaking near you while you wear the speaker on neck. To reduce the risk of electric shock or damage to your equipment: ‐... -
Page 5: Limited Warranty Statement
‐ Avoid over‐bending the strap. ‐ Do not use “Music Wrap” with improper or dangerousactions. Caution: The speaker containing battery part should not be exposed to excessive heat such as fire, sunlight, or other concentrated heat surfaces. Limited Warranty Statement: ‐ The warranty period for Music Wrap product is one (1) year from the date of purchase by the original end user customer from Music Wrap’s authorized distributors. Music Wrap product shall be free from defects in material and workmanship. ‐ The warranty above does not cover defects resulting from abuse or misuse, improper storage, or negligence (to the extent caused by any person or entity other than supplier), improper installation by end user customers, or any warranty claim made after the expiration of the product warranty period. ‐ During the warranty period and upon authorization by a service technician, we will repair or replace the defective parts free of charge. Repair or replacement of defective parts which are out of the warranty coverage will be subject to additional service fees. ‐ The warranty aboveshall be void if the label bearing the serial number has been removed or defaced. FCC Statement: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and ...
