Decals Group - Simplicity 13.5HP Parts Manual

Decals Group

NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
1
DANGER
KEEP HANDS and FEET AWAY
10
+R
Ref. No. 10 Apply to
S/N 012003001 and Up Only
The above parts group applies to the following Mfg. Nos.:
1694240 - 13HP 1694252 - 15HP
1694204 - 13.5HP 1694249 - 13HP
1694205 - 15HP 1694254 - 13HP
1694251 - 13.5HP 1694378 - 13HP
1694253 - 13.5HP 1694379 - 15HP
1694250 - 15HP N/A - 16HP
© Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved.
2
EAR EYE BREATHING PROTECTION
9
8
7
SPEED ADJUST
+F
1
3
DANGER
CAUTION
ROTATING PARTS KEEP HANDS and FEET AWAY
1. BEFORE OPERATING READ OPERATORS MANUAL
FOR OPERATING AND SAFETY INSTRUCTIONS.
2. DO NOT OPERATE WITH ANY GUARDS OR
COMPONENT PARTS REMOVED FROM UNIT.
3. BEFORE MAKING ANY ADJUSTMENTS OR REPAIRS
STOP ENGINE AND REMOVE SPARK PLUG WIRES.
4. WHILE IN OPERATION KEEP ALL PARTS OF BODY
AWAY FROM INTAKE AND EXHAUST SECTIONS.
5. WHEN OPERATING MACHINE KEEP PEOPLE AND
PETS A SAFE DISTANCE AWAY.
FREE
WHEEL
22
4
DANGER
DANGER FLYING MATERIAL
1
DANGER
KEEP HANDS and FEET AWAY
DRIVE 5
6
OFF
ON
START
TP 400-2570-02-BC-UV
986133
