Quick Start Guide
VeriFone MX915 + Motorola QR Reader
Your package should arrive with one box containing the MX915 and, if selected, a second box containing the DS9208. A
network ethernet cable will also be provided. Other optional power cables and networking cables may be required for your
unique installation along with wired internet access such as a router (not provided).
1.
Utility Cable
2.
Genius CED (VeriFone MX915)
3.
AC Adapter (for VeriFone MX915)
Connecting Genius
The Utility Cable handles the wiring for Genius CED. Once
this cable is connected in to Genius, no other cables connect
to Genius. Rather, everything is connected to the utility cable.
Get this cable now to begin installation.
The utility cable has four open slots for other cables to
connect to it, as illustrated.
1.
2.
3.
1
2
3
QZ
ABC
DEF
4
5
6
GHI
JKL
MNO
7
8
9
PRS
TUV
WXY
0
Ethernet
+12V
Audio
USB
HOST
