| Paradigm flush wall switches
™
feature a contemporary design and a wirefree
deployment, making them retrofit ready for any
location. Paradigm 5 channel switches are
perfect for individual shade, room and whole
home control.The Paradigm flush mount switch
can be mounted on top of any surface. Its slim
profile eliminates the need for any holes to be
cut in walls.
™
Paradigm Flush Wall Switch
433 MHz
Custom Made Smart.
FEATURES:
• Multi channel selectable
• Retrofit Ready
• Group Control
• Compatible with screwless decorator cover plates
• Optionally functions as handheld remote
Advertisement
Table of Contents
Related Manuals for Tiger Window Fashions AUTOMATE
Summary of Contents for Tiger Window Fashions AUTOMATE
- Page 1 AUTOMATE ™ Paradigm Flush Wall Switch 433 MHz AUTOMATE | Paradigm flush wall switches FEATURES: ™ feature a contemporary design and a wirefree • Multi channel selectable deployment, making them retrofit ready for any • Retrofit Ready location. Paradigm 5 channel switches are perfect for individual shade, room and whole •...
-
Page 2: Table Of Contents
ADJUSTING LIMITS 7.1 Adjusting upper limit 7.2 Adjusting lower limit FAVORITE POSITIONING 8.1 Set a favorite position 8.2 Send shade to favorite position 8.3 Delete favorite position TROUBLESHOOTING 2 | Automate Programming Instructions | Flush Wall Switch TIGER WINDOW FASHIONS ™... -
Page 3: Technical Data / Pack Contents
TECHNICAL DATA / PACK CONTENTS TECHNICAL SPECIFICATIONS Voltage: 3V (CR2430) Frequency: 433.92 MHz Transmitting Power: 10 milliwatt Ambient Operating Temperature: -10°C -50°C Transmission Distance: up to 200 meters (open space) TIGER WINDOW FASHIONS Automate Programming Instructions | Flush Wall Switch | 3 ™... -
Page 4: Safety
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Do not dispose of in general waste. 5005833 Please recycle batteries and damaged electrical products appropriately. 4 | Automate Programming Instructions | Flush Wall Switch TIGER WINDOW FASHIONS ™... -
Page 5: Installation
Open rear battery cover by gently separating Install CR2430 battery with positive side facing switch covers with a screwdriver up. Snap covers back together. Snap covers back together. TIGER WINDOW FASHIONS Automate Programming Instructions | Flush Wall Switch | 5 ™... -
Page 6: Magnetic Wall Clip
Use supplied fasteners and anchors as needed to attach the base and cover. Switch is secured unless the Cover is removed. Safely dispose of the unused Magnetic Wall Clip. 6 | Automate Programming Instructions | Flush Wall Switch TIGER WINDOW FASHIONS... -
Page 7: Functional Overview
Blue LEDs will illuminate indicating channel selection. Switch requires that at least one channel be selected at all times. First select an additional channel, then deselect channel you don't want to operate. Programming Instructions | Flush Wall Switch | 7 TIGER WINDOW FASHIONS Automate ™... -
Page 8: Programming
• Ensure that each motor you want to group is also assigned to another channel by itself Select a channel on Hold P1 button on motor Hold STOP on switch. switch. head. 70.59% Motor Response Motor Response RELEASE P1 Approx. Approx. 8 | Automate Programming Instructions | Flush Wall Switch TIGER WINDOW FASHIONS ™... -
Page 9: Using A Pre-Existing Controller
Press P2 a second time on Select desired channel on new switch. Press P2 on operates motor on existing switch. existing switch. new switch. Press P2 Motor response Motor response Motor response Programming Instructions | Flush Wall Switch | 9 Automate TIGER WINDOW FASHIONS ™... -
Page 10: Initial Setup
IMPORTANT For FT Motors, the bottom limit should be set ~ 1.38 in. (35mm) below the Ultra-Lock to disengage the auto lock mechanism when the shade is raised. 10 | Automate Programming Instructions | Flush Wall Switch TIGER WINDOW FASHIONS... -
Page 11: Locking The Limit Setting Function
All lights flash x 2 IMPORTANT The locked setting will prevent any multi-button functions. These include reversing direction before setting limits, limit setting and toggling between tilt and roller modes. Automate Programming Instructions | Flush Wall Switch | 11 TIGER WINDOW FASHIONS ™... -
Page 12: Adjusting Limits
IMPORTANT For FT Motors, the bottom limit should be set ~ 1.38 in. (35mm) below the Ultra-Lock to disengage the auto lock mechanism when the shade is raised. 12 | Automate Programming Instructions | Flush Wall Switch TIGER WINDOW FASHIONS... -
Page 13: Favorite Positioning
Send shade to favorite position Approx. Delete favorite position Press P2 on controller. Press STOP on controller. Press STOP on controller. Motor Response Motor Response Motor Response TIGER WINDOW FASHIONS Automate Programming Instructions | Flush Wall Switch | 13 ™... -
Page 14: Troubleshooting
Press and hold STOP button for 15 Motor will pair, but can not set Control must be unlocked limits. to set limits or perform any seconds, until locked state changes. multi-button functions. 14 | Automate Programming Instructions | Flush Wall Switch TIGER WINDOW FASHIONS ™... - Page 15 NOTES TIGER WINDOW FASHIONS Automate Programming Instructions | Flush Wall Switch | 15 ™...
- Page 16 Custom Made Smart. Tiger Window Fashions 400 West Main Street Suite 327 Babylon, NY 11702 877-835-5036 www.TigerWindowFashions.com...
