SALTBURN / DALBY SMOKE CONTROL ISSUE 2
06/07/2015
SALTBURN SMOKE CONTROL /
DALBY SMOKE CONTROL
WOOD BURNING STOVE
INSTALLATION AND USER INSTRUCTIONS
Read these instructions carefully before installation and use.
These instructions should be retained by the user for future reference.
Please note these instructions cover 2 models of stoves;-
The Saltburn Smoke Control (flat door version)
and the
Dalby Smoke Control (curved door version)
The Saltburn / Dalby Smoke Control stove has a nominal heat output of 5kW and a
weight of 61 kg. The flue gas mass flow is 2.9 g/s for wood logs. The mean flue gas
temperature directly downstream of the flue spigot at nominal heat output is 233 degrees C.
The Saltburn / Dalby Smoke Control has been tested as a closed appliance and is capable of
intermittent operation.
WARNING
The stove must be installed to comply with Health and Safety at Work Act 1974,to British
Standard BS 8303 and to all local Building Regulations, including those referring to
National and European standards.
These need to be complied with when installing the appliance.
Ensure that the flue pipe diameter is not less than the 125mm diameter outlet on the
appliance.
There must not be an extractor fan fitted in the same room as the Saltburn / Dalby Smoke
Control.
If there is a possibility of disturbing asbestos during the installation it is necessary to take
the appropriate steps to protect the installer.
Fire cement is caustic and protective gloves should be worn.
The chimney must be swept and examined for soundness and suitability before the stove is
installed. Remedial action should be taken if required, seeking expert advice if necessary.
Where the chimney is believed to have previously served an open fire installation it is
possible that the higher flue gas temperature from a closed appliance may loosen deposits
that were previously firmly adhered, with the consequent risk of flue blockage.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SALTBURN SMOKE CONTROL and is the answer not in the manual?

Questions and answers

Summary of Contents for Town & Country Fireplaces SALTBURN SMOKE CONTROL

  • Page 1 Read these instructions carefully before installation and use. These instructions should be retained by the user for future reference. Please note these instructions cover 2 models of stoves;- The Saltburn Smoke Control (flat door version) and the Dalby Smoke Control (curved door version) The Saltburn / Dalby Smoke Control stove has a nominal heat output of 5kW and a weight of 61 kg.
  • Page 2 Order made and signed by the Secretary of State or Minister in the devolved administrations. The Saltburn Smoke Control and the Dalby Smoke Control have been recommended as suitable for use in smoke control areas when burning dry seasoned wood logs and when the appliances have been modified to prevent closure of the air control slider beyond the 30mm open position.

  • Page 3: Unpack The Stove

    SALTBURN / DALBY SMOKE CONTROL ISSUE 2 06/07/2015 UNPACK THE STOVE Carefully cut the straps and lift the box up over the top of the stove. Remove the packing from round the outside of the stove, leaving the plastic cover on if building work is still in progress.
  • Page 4 SALTBURN / DALBY SMOKE CONTROL ISSUE 2 06/07/2015 before installation. If the chimney requires lining a lining must be used which is suitable for wood and solid fuel, with a minimum of 125mm internal diameter. A meter of flue pipe should be used from the stove before the chimney lining, and the lining must be installed to manufacturers’...

  • Page 5: Lighting The Stove

    SALTBURN / DALBY SMOKE CONTROL ISSUE 2 06/07/2015 TURBO BURNER There is a Turbo Burner which brings air in allowing plenty of oxygen into the rear and top of the stove, thus burning off gases which normally do not ignite. This gives the stove more efficiency and better combustion, less pollution.
  • Page 6 SALTBURN / DALBY SMOKE CONTROL ISSUE 2 06/07/2015 Operation with the stove door open can cause excessive smoke. The appliance must not be operated with the stove door left open. STOVE HANDLE COVER There is a black stove handle cover included with your stove this is to be used when opening and closing the stove door.
  • Page 7 SALTBURN / DALBY SMOKE CONTROL ISSUE 2 06/07/2015 FUELS This appliance has been tested using seasoned wood logs. The logs need to be dry, seasoned logs i.e.no more than 20% moisture content, maximum log size for use in the appliance is length 350 mm x 75mm diameter Small pieces of kiln dried timber can burn very hot, take care that the fire does not get out of control.

  • Page 8: Troubleshooting

    SALTBURN / DALBY SMOKE CONTROL ISSUE 2 06/07/2015 TROUBLE SHOOTING 1. The stove is not burning well. The stove may need more fuel loading - load more fuel, see ‘lighting the stove’ The wood may be un-seasoned or damp – don’t use unsuitable wood. The chimney may need sweeping, or there may be a build up of debris above the baffle - see ‘Cleaning the Stove and Flue’...
  • Page 9 Guard, Door Rope kit, Glass seal and Door Glass - in this instance please advise the dealer when ordering if your stove is the Saltburn Smoke Control – ( flat door version ) or Dalby Smoke Control – ( curved door version).
  • Page 10 Installation / User instructions supplied with the stove. Installation must be carried out by a competent installer. The Saltburn Smoke Control and Dalby Smoke Control are wood burning stoves. Using a fuel other than dry seasoned wood logs (maximum 20% moisture content) may cause damage to the stove and will not be covered by our guarantee.
