Euronics Sole cleaning machine Operation Manual

Sole cleaning machine operation manuals
I．Instruction
1、 Placed sole cleaning machine on flat ground;
2、 Placed dry pad on cover plate, side of dry pad into quadrilateral frame;
3、 Unlock on two sides, then open the cover, please referring to Figure1.1;
4、 Add water, level line between "min" and "max"；
5、 Close the cover slowly and lock it, connect the power.
6、 Before removing make sure it locked
Handle
Holder
Lock
Figure1.1
II. Usage
For the best cleaning result, pls pass through cleaning and dry zone referring to Figure 2.1-2.2. First the
cleaning zone. On the dry zone stay 2 seconds. More time cleaning, the effect will be better.
1、Pls stand upon clean zone as arrow
III. Maintenance
1、Cleaning machine: Regular clean the dust of the machine and brushes surface dirty.
2、Cleaning dry mat: Clean once every day, or more times than that, just depend on the actual situation to keep
the dry mat clean and absorbing effect. After cleaning, reset the mat to dry zone. Do not wring dry mat to
prevent damage. If you don't use the mats, seal it with plastic film.
3、Changing water:
1) Power off, unlock two sides, lift up cover;
2) Back tank, referring to figure 3.3.1;
3) Lift tank handle, referring to figure 3.3.1;
4) Out of tank, water pouring, cleaning tank, add water to the liquid level scale, referring to figure 3.3.2;
5) Replace the tank;
6) Close cover slowly and lock it, then connect the power.
第六步，手扶着上壳慢慢放下，锁住锁扣，接通电源。
Cover
Sensor
Tank
Lower casing
Level indication
2、Piaffe 4 times
Figure2.2
Clean zone
Power interface
Figure2.1
3、Pls walk to the dry zone, stay 2s
around.
1
Dry zone
区。
