INID XS series Installation Manual

number name
5040C INID SmartReader XS PIN
5000C INID SmartReader XS
5045C INID MultiSmart XS PIN
5005C INID MultiSmart XS
5240C INID SmartProx XS PIN
5200C INID SmartProx XS
Classifications
UL 294:
destructive attack level IV, line security level I,
endurance level IV, standby power level I
ULC S319:
class III
Specifications
Dimensions
143 x 50 x 25 mm / 5⅝ x 2 x 1 inch
Operating temperature
-25° to 65° C / -15° to 150° F
Protection class
IP54 Complete protection against contact, protection
against dust deposit.
Protection from splashed water.
Power Supply
All models 7.0 - 24 Volt DC
models
5000C INID SmartReader XS
5040C INID SmartReader XS PIN 1,50 2,55 215 365 125 215
5005C INID MultiSmart XS
5045C INID MultiSmart XS PIN
5200C INID SmartProx XS
5240C INID SmartProx XS PIN
Note: Ohms' Law may be used to estimate current at other voltages.
Parts included
(1 each)
Reader front
Mounting backplate
Enclosure screw (Torx #8)
Installation manual
Document 100.14.IS.01 v1.30, effective from SN1632-0001
INID XS readers Installation Manual
Models
interfaces
WG/C&D/TTL + RS485
WG/C&D/TTL + RS485
WG/C&D/TTL + RS485
WG/C&D/TTL + RS485
WG/C&D/TTL + RS485
WG/C&D/TTL + RS485
mA
Watts
at V at 12 V
min
avg peak avg peak avg peak avg peak
1,50 2,35 215 340 125 200
1,50 2,35 215 340 125 200
1,50 2,55 215 365 125 215
0,85 2,00 125 290 75 170
0,85 2,00 125 290 75 170
Certifications
CE, FCC, IC, UL, ULC
FCC ID: YAB-MSXSRDR
YAB-SPXSRDR
YAB-SRXSRDR
IC: 8908A-MSXSRDR
8908A-SPXSRDR
8908A-SRXSRDR
Consult your National Authority if any authorization is needed for
these products.
Warning (part 15.21)
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment.
Compliance statement
This device complies with part 15 of the FCC Rules and with the
Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
article
(2) l'utilisateur de l'appareil doit accepter tout brouillage
number
radioélectrique subi, même si le brouillage est susceptible d'en
500-5040C
compromettre le fonctionnement.
500-5000C
500-5045C
Information to the User (Part 15.105 (b))
500-5005C
Note: This equipment has been tested and found to comply with the
500-5240C
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
500-5200C
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
Complies with: CAN ICES-3 (B)/NMB-3(B)
Operation
When a credential is read successfully, the LED bar lights briefly, the
sounder sounds a short tone and the credential associated code is sent
to the Host system.
The LED bar and sounder are also controllable by the Host system.
When a PIN is entered the data is sent to the Host system; at each key
at V
DC max
press a click sound is produced and the LED bar lights briefly. The
backlight of the PIN code lights up after a successful credential read, or
65 100
at the first key press.
65 110
Reader output formats are determined by the personalization of the
65 100
credential and/or configuration of the reader; on SmartReader and
65 110
MultiSmart readers the behaviour of the LED bar and sounder can be
40 85
modified through configuration.
40 85
When the reader detects a tamper status, the LED bar flashes red and
the tamper output is activated; on SmartReader and MultiSmart
readers this behaviour can be modified through configuration.
page 1 of 2
(MultiSmart XS readers)
(SmartProx XS readers)
(SmartReader XS readers)
(MultiSmart XS readers)
(SmartProx XS readers)
(SmartReader XS readers)
INID BV
Overweg 5
1713 HX Obdam
The Netherlands
Phone: +31 (0)226 450 009
Web: www.inid-readers.com
printed on Aug 8, 2016
