MV-ALS-Series
Quick Reference: Portable Receiver
Unit Controls
The Media Vision portable receiver offers a selection of 57 channels and an OLED display which indicates battery life, signal
strength, volume and a channel selection. The unit is lightweight and can accomopdate multiple headset options for a
comfortable listening experience for the user. Needed (not included): earphone, headphone or neckloop, optional rechargeable
or alkaline AA batteries.
REMOVABLE CLIP
USB
4
POWER
HEADPHONE JACK
OLED SCREEN
NAVIGATION
BATTERY DOOR
REMOVABLE CLIP ON BACK
(MV-ALS-PRFM)
MODE INDICATOR
SIGNAL STRENGTH
SET
CHARGING CONTACTS
CHANNEL
LOCK INDICATOR
BATTERY LIFE
INDICATOR
When this segment begins
flashing along with the
LED on top of the unit,
you should immediately
change your batteries or
recharge them.
www.media-vision.com
50% or more
25-49%
Less than 25%

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MV-ALS-PRFM and is the answer not in the manual?

Questions and answers

Summary of Contents for Media Vision MV-ALS-PRFM

  • Page 1 Unit Controls The Media Vision portable receiver offers a selection of 57 channels and an OLED display which indicates battery life, signal strength, volume and a channel selection. The unit is lightweight and can accomopdate multiple headset options for a comfortable listening experience for the user.

  • Page 2: Channel Change

    1. Press and hold power button for 1 second till logo “Media Vision” shows up. 2. Logo “Media Vision” shows up for 2 seconds, and then OLED becomes dim. 3. The screen shows default (CH E)/previously used channel or custom label,...

  • Page 3: Led Indicators

    MV-ALS-Series Quick Reference: Portable Receiver (MV-ALS-PRFM) LED Indicators 1. When the player is on and doesn’t receive signal from transmitter, LED will turn to be solid red and “bar” symbol flashes. (Symbol flashes with solid red LED.) 2. When the player is on and with low battery, LED will turns to be solid red and “battery” symbol flashes.

  • Page 4: Unit Controls

    MV-ALS-Series Quick Reference: Stationary Transmitter (MV-ALS-STFM) MV-ALS-STFM-D (Dante-enabled version) Unit Controls 72-76 MHz FM, 57 programmable channels, balanced and unbalanced inputs, balanced outputs, OLED display, access to software interface. Tabletop or rack-mounting, power cord and USB programming cable included, optional Helical or Remote Antenna needed (not included).

  • Page 5: Signal Strength

    (MV-ALS-STFM) Turn-On 1. Press and hold power button for 1 second till logo “Media Vision” shows up, which will stay for 2 seconds. 2. The screen shows default channel (E) or custom label, symbol “wideband” ( ), symbol “lock” (...
  • Page 6 MV-ALS-Series Portable Transmitter Quick Reference (MV-ALS-PTFM) Portable Transmitter 72-76 MHz FM, operating range: up to 100 feet, 57 programmable channels, settings lock, OLED display. Needed (not included): microphone, optional rechargeable or alkaline AA batteries. MODE INDICATOR POWER / MUTE MIC INPUT CHANNEL MIC LEVEL LOCK INDICATOR...
  • Page 7 1. Press and hold power button for 1 second till logo “Media Vision” shows up. 2. Logo “Media Vision” shows up for 2 seconds, and then OLED becomes dim. 3. The screen shows default (CH E)/previously used channel or custom label,...

  • Page 8: Mic-Level Adjustment

    MV-ALS-Series Portable Transmitter Quick Reference (MV-ALS-PTFM) MV‐ALS‐PTFM brief instruction manual  th  v.1 (11 Dec. 2015) 3. To release the player from lock mode, press both + and – at the same time for 1 second until symbol    disappears.  MV‐ALS‐PTFM brief instruction manual  th  v.1 (11 Dec. 2015) LED Indicators MV‐ALS‐PTFM brief instruction manual  LED indicators  th  v.1 (11 Dec. 2015) 3. To release the player from lock mode, press both + and – at the same time for 1 second until symbol    disappears.  1. When the player is on and with low battery, LED will turns to be solid red and “battery” symbol flashes. 1. When the player is on and with low battery, LED will turns to be solid red and “battery” symbol flashes. 3.

  • Page 9: Reset To Default Setting

    Charger 1. Auto-off 2. No symbols on the screen 1. Autooff 2. Logo “Media Vision” shows up for 2 seconds, and then USB symbol displays. 3. LED indicator is the only way to know the charging status when PC connected.
  • Page 10 Software Introduction portion of the Manual Uploading Receiver Software Uploading  1. When the player is connected with PC, it will show logo “Media Vision” for 2 seconds, and then symbol “USB”. 1. When the player is connected with PC, it will show logo “Media Vision” for 2 seconds, and then symbol “USB”. 2. Status column in proprietary software shows message of successful connection.
  • Page 11 1. After being plugged in the socket, it can be uploaded while micro USB is connected with PC. 1. When the player is connected with PC, it will show logo “Media Vision” for 2 seconds, and then symbol “USB”. 2. When the system is connected with PC, it will show logo “Media Vision” for 2 seconds, and then symbol “USB”. 3. Status column in proprietary software shows message of successful connection.

  • Page 12: Fcc Statement

    FCC statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
