Installation, Operation and
Maintenance Manual
PeakFlowE
Model #GXXX001725
PeakFlowE
Anti-Scale System
™
Chemical-Free, Salt-Free Scale Prevention
!
WARNING
Read this Manual BEFORE using this equipment.
Failure to read and follow all safety and use information
can result in death, serious personal injury, property
damage, or damage to the equipment.
Keep this Manual for future reference.
Introduction
The PeakFlowE Anti-Scale System provides protection from scale
TM
formation on internal plumbing surfaces. The PeakFlowE system
is a single cartridge-based system that must be installed on a
cold water line prior to a single residential water heating device
(water heater or tankless water heater).
The PeakFlowE system is built with the finest and most advanced
TM
materials and each system is quality inspected and pressure
tested prior to shipment. With proper installation and routine
maintenance, you will have years of trouble-free operation.
Please refer to this manual when performing routine filter changes.
The instructions make periodic maintenance quick and easy and
ensure you will receive maximum benefit from your system.
System Specifications
Maximum Pressure:
90psi / 6.2 bar
Maximum Temperature:
Minimum Temperature:
Service Flow Rate:
Up to 6 gpm (23 lpm)
Continuous Flow Rate:
Up to 4 gpm (15 lpm)
Inlet/Outlet Connections:
Capacity: Media cartridge does not have a grain removal capacity.
However, other contaminants present in the water will gradually
degrade the e ectiveness of this cartridge. Change the PeakFlowE
media cartridge (#GXXX001726) at least once every two years.
!
WARNING
• Connect system to cold water supply only. Water temperature
cannot exceed 100°F / 38°C.
• System must be installed in a vertical, upright and level
position.
• PeakFlowE
systems must not be used in conjunction with
TM
polyphosphate or any other scale inhibitor.
• Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or after
the system.
100°F / 38°C
40°F / 5°C
/
" FNPT
3
4
TM
TM
TM
