Repair Parts

1
1A
1B
1C
1D
1F
1E
1B
Key No.
1
1A
1B
1C
1D
1E
1F
1G
2
3
4
5
6
* Included in Hardware Replacement Kit, Key No. 1.
** If pump fails, replace entire system.
NOTE: Key No. 1G Check Valve Assembly must be correctly installed or warranty is void. If
primary sump pump has no check valve installed below the Battery Backup Tee, Key No. 1D
Auxiliary Check Valve must be correctly installed or warranty is void.
For parts or assistance, call Simer Customer Service at
3
2
1G
Part Description
Hardware Replacement Kit (Includes Key Nos. 1A through 1G)
Rubber Hose Coupling with Inserts (2) and Clamps (2)
1-1/2 x 1-1/4 PVC Slip Reducer Bushing (2)
PVC Tee 1-1/2 x 1-1/2 Slip x 1-1/4 FNPT
Auxiliary Check Valve
1-1/2 x 1-1/2 PVC Slip Coupling
PVC Pipe Nipple, 1-1/4 NPT x Close
Check Valve Assembly, 1-1/4 FNPT x 1-1/4 FNPT
DC Backup Pump
Vertical Float Switch Package
Charger
Battery Case (Complete)
AC Adaptor
Electrical Replacement Kit (Includes Area Light LED and
Battery Leads)
4
5
Part Number
PS198-270
U74-68
*
*
*
*
*
*
**
PS198-269REP
PS217-1512
PS17-1512
PS17-1530
PS1513REP
1-800-468-7867 / 1-800-546-7867
11
6
5767 0108
