  • Page 1 Installation Guide...
  • Page 2 ×2 ×2 ×2 ×2 ×2 ×1 ×1 ×2 ×1 ×2 3.0 Spanner 4.0 Spanner Battery Drilling Template Manual Smart Door Lock User Guide ×10 ×2 ×1 ×2 ×1 ×1 Back Panel Front Panel Lock Body Strike Plate ×1 ×1 ×1...
  • Page 3 ×2 ×2 ×2 ×2 ×1 ×2 ×2 ×1 Drilling Template Manual 1.5 Spanner 3.0 Spanner 4.0 Spanner Battery Smart Door Lock User Guide ×10 ×1 ×2 ×2 ×1 ×1 ×1 Back Panel Front Panel Lock Body Strike Plate Strike Box ×1...
  • Page 4 3. Installation Note 1. Check the products and accessories according to the product list. 2. Check the specifications of the products. 3. Check the accessories package to see whether the guide plate and strike plate are matched with your door. 4.
  • Page 5 4. Con rm the Drilling on the Door Confirm whether the drilling is matched with the drilling drawing, if not, please redrill according to the drawing. Do not close the door before the complete installation. Drilling Drawing Guide plate drilling drawing...
  • Page 6 5. Guide Plate Replacement 1. Open the deadbolt, take off the screws and the guide plate. 2. Replace the guide plate. 3. Screw on and reset the deadbolt.
  • Page 7 6. Open Direction Changing in the Lock Body Initial open direction: Right outward. After changing the direction, screw on the hex screw and ensure that the screw top faces indoor. 180° Change the direction of the oblique deadbolt 1. Push the reversing piece upwards 2.
  • Page 8 7. Direction Changing of the Handle Below is the direction changing illustration of the handle of the front panel. For the handle of back panel, please refer to this.
  • Page 9 8. Front and Back Panel Accessories Installation Respectively install the screw cover, handle shaft spring, thumb-latch shaft and key shaft. Notes: Screw on tightly after adjusting the thumb-latch shaft and key shaft.
  • Page 10 9. Lock Body Installation Upside-down triangle...
  • Page 11 10. 8 X 8 Handle Shaft Installation Adjust the hole direction of the lock body shaft during the installation.
  • Page 12 11. Install the Front Panel Infix the lock body cable and install the front panel. Notes: Do not insert the key.
  • Page 13 12. Wiring of the Back Panel Pay attention to the wire direction.
  • Page 14 13. Install the Back Panel and Screws Arrange the cables to avoid interference. Insert the cable in the hole Aline the thumb-latch vertically...
  • Page 15 14. Install the Battery Cover and Insert Batteries...
  • Page 16 15. Strike Plate & Strike Box Installation...
  • Page 17 16. Installation Acceptance ∥ ∥ ∥...
  • Page 18 17. Installation Acceptance Criteria 1. Turn the front handle and back handle smoothly with normal springback. 2. Turn the front handle and back handle to enable the square deadbolt. 3. The front panel and back panel are parallel with the door frame. 4.
