Summary of Contents for Oceania Optimale Series
- Page 1 Installation Instruction for Optimale Series Side Mounting (MC)
- Page 2 1. Place the bathtub and the base in their final 2. Remove the bathtub and install the base as position. Adjust the legs of the bathtub so that they described in the Installation Manual provided with the support the tub. Make sure that the tiling flange of the base.
- Page 3 5. Apply a generous line of silicone on the side of the 6. Remove the blocks and place the bathtub in its base where it comes into contact with the bathtub (along final position, and connect the drain. the tiling flange). 7.
- Page 4 11. For Marelia Sliding Door 12. For California Hinged Door Install special door panel MC32SD Install special door panel MC32B1 Secure aluminum wall jamb on the wall, at 1/4’’ Secure aluminum wall jamb on the wall until (6.3mm) from the side of the bathtub. the extrusion is aligned with the side of the bathtub.
- Page 5 15. Installation panel (optionnal) Apply a bead of silicone in the cavity made for that purpose, all around the panel. Install the panel on the bathtub, bottom being on the shower base and panel being centered (right/left). Remove excess of silicone. Note : use masking tape to hold the panel in place while silicone is drying.
