Summary of Contents for ELECREALM M.NT68676.2A
- Page 1 User's Guide of M.NT68676.2A Controller Board V1.1 2014-03-28 ELECREALM http://www.elecrealm.com/...
- Page 2 Content Chapter 1--Cable connection ............. 2 Chapter 2--The LCD Panel Voltage Jumper ......6 Chapter 3--How to enter into factory mode ....... 8 Chapter 4--Upgrading the M.NT68676.2A firmware....16 Chapter 5--Troubleshooting............. 26 1 / 27...
- Page 3 Chapter 1--Cable connection 2 / 27...
- Page 4 Please check the inserting condition of each foot. If some foot is not fully inserted (as shown in the figure below), please use tweezers to press the exposure to the top of the foot, let all feet be inserted into well.
- Page 5 4 / 27...
- Page 6 5 / 27...
- Page 7 Chapter 2--The LCD Panel Voltage Jumper The board voltage and the LCD voltage are 2 different parameters. The board can be worked from +5V to +12V. The LCD voltage only can be supplied by the board’s jumper with only +3.3V +5.0V +12.0V. Most of LCD panel works at +3.3V. Normally, the board’s jumper has been jumped to +3.3V and please don’t jump it again.
- Page 8 7 / 27...
- Page 9 Chapter 3--How to enter into factory mode 8 / 27...
- Page 10 9 / 27...
- Page 11 10 / 27...
- Page 12 11 / 27...
- Page 13 12 / 27...
- Page 14 13 / 27...
- Page 15 14 / 27...
- Page 16 15 / 27...
- Page 17 Chapter 4--Upgrading the M.NT68676.2A firmware Tools: VGA Cable—1pcs Parallel Programmer--1pcs Parallel Cable—1pcs The steps： Please confirm your PC has been installed the Parallel port driver program. If it isn’t installed, please install it first. Step 1. Installed the Parallel port driver program on the PC.
- Page 18 Step 2. Connect the cables as follows. 17 / 27...
- Page 19 18 / 27...
- Page 20 19 / 27...
- Page 21 Step 3. Double click the Easy WriterV2011.0831_W7.exe file to start software driver installation. Then, the setup program will guide user to complete software installation. 20 / 27...
- Page 22 Step 4. Then run EasyWriter_V2010 software, a new dialog popped up as below. Press button, and select 21 / 27...
- Page 23 Step 5. Then press , a new dialog popped up as below. Press the left button and finish the software configuration. Step 6. Press Option, remove the selection of 22 / 27...
- Page 24 Step 7. Press Load File, a new dialog popped up as below. Select the bin file on the 23 / 27...
- Page 25 Step 8. Press to burn bin file to the driver board. 24 / 27...
- Page 26 图 6 Step 9. A new dialog popped up as below, the total process finished. ，then Step 10. If the upgrading procedure is failed, please press press , then press and re-burn the bin file to the board. 25 / 27...
- Page 27 Chapter 5--Troubleshooting Question 1 – The power adapter requirement of the board. The board voltage and the LCD voltage are 2 different parameters. The board can be worked from +5V to +12V with 3.0A current. Question 2 – The LCD panel voltage The LCD voltage only can be supplied by the board’s jumper with only +3.3V +5.0V +12.0V.
