- Page 1 Pasta Maker User Manual PKPM350 NutrichefKitchen.com...
-
Page 2: Product Features
Product Features 1. With several noodle molders, you can make noodles from narrow to wide, square to round. 2. You may put egg or sauce to make healthy noodles. 3. Simple operation: flour in, noodles out. 4. Food class materials for safe usage. 5. - Page 3 Disassembly 1) Take off the fastening screw, and then Noodle Molding. See Figure 1 and 2. 2) Take off the Front Panel, Mixing Tank and Mixing Screw. See Figure 3. How to Assemble 1) Put the Product on a stable counter, then put the Mixing Tank into the product. Insert the Mixing Axis into the device.
- Page 4 Noodle Molding Replace Loosen the Fastening Screw and take off the Noodle Molding. Put the replaced Noodle Molding into the Mixing Axis and then tighten the Fastening Screw. As shown in the Figure below: Remarks: When replacing the noodle mold, you only need to loosen/fasten the bigger screw in middle, no need to fasten/loosen the two small screws.
- Page 5 How to Make Noodles Step 1: Press the Mixing Tank cover button. The cover will automatically open. Then, put the flour in the Mixing Tank. Close the cover. Step 2: Press the button “Automatic” or “Mixing”. The Mixing Axis will start to mix the flour. Then put the correct amount of water into the cover slot.
- Page 6 Control panel Automatic Mode 1) Press “Automatic” one time, use two measuring cup of flour. Mixing time is 4 minutes, and the noodles will come out within 12 minutes. After the mixing is done, the axis will reverse for 8 seconds. If not all of the noodles come out, press the “Out” and the noodles will continue come out.
-
Page 7: Cleaning And Maintenance
Remark of making noodles 1) Proportion of flour and water One Flour Cup of flour mixed with one Water Cup water. However, this may vary due to different conditions. 2) While making noodles, if the paste is very loose while the noodles already started coming out, this may damage the machine. - Page 8 Cautions 1. Before assemble the Noodle Molding into machine, put it into hot water for one minute. This can help the noodles come out much easier. 2. After continuous working of 3 times, the machine must stop and rest for 10 minutes. 3.
- Page 9 Q & A 1. The machine cannot be energized. a) The Lid Cover was not closed well. Close the Lid Cover. b) The Fasten Screw is not locked well. Screw the Fasten Screw firmly. 2. No noodles are coming out. a) Too much water during mixing.
-
Page 10: Technical Parameter
9) The Noodle Molding/supporting board cracked, or the mixing axis broken. The paste is too dry and will damage the machine, please contact service center and replace the new parts. Technical Parameter Product rating Product Name Noodle Maker Model Number PKPM350 Voltage 220V Frequency 50Hz Wattage 180W...
