Quick guide spo-book EXPANDED Q170
Please check before you start the device:
• If the device temperature conforms to the recommended operating temperature.
• If the power source is correctly connected.
• If all adaptors and connectors are properly connected.
1. Front Panel:
2. Rear Panel:
1. USB 2.0 Ports
2. HDD LED
3. Power Button
4. RS-232 Serial Port
5. Display Port
6. HDMI Port
7. VGA-Port
8. RJ45-GbE-LAN
9. USB 3.0 Port
10. Audio Out
11. Microphone In
12. PCIe
13. power connector
Advertisement
Table of Contents
Related Manuals for spo-comm spo-book EXPANDED Q170
Summary of Contents for spo-comm spo-book EXPANDED Q170
- Page 1 Quick guide spo-book EXPANDED Q170 Please check before you start the device: • If the device temperature conforms to the recommended operating temperature. • If the power source is correctly connected. • If all adaptors and connectors are properly connected.
- Page 2 4.3. pxe-Boot: boot an OS via LAN and DHCP. -> Boot -> Launch PXE OpRom Policy 5. Drivers: The drivers for the spo-book EXPANDED Q170 can be found in our product catalog on the product page under the tab "Product Details and Downloads" and on the supplied driver stick.
