Feiss WB1842 Installation Instructions

Installation Instructions for
Paulson Wall
Wall
G ENERAL RODUCT NFORMATION P
These fixtures are intended to be installed utilizing
boxes.
This product is safety listed for damp locations.
Incandescent lamps may be dimmed with a standard incandescent dimmer.
LED lamps may be dimmed with a
additional information.
1A
JUNCTION BOX
1
Secure the mounting plate to the junction box.
2
Connect the fixture ground wire to a suitable ground in accordance to local electrical codes.
3
Connect the white fixture wire to the neutral power line wire with a wire nut.
4
Connect the black fixture wire to the hot power line wire with a wire nut.
5
Mount the fixture base onto the mounting plate and secure it with the set screw using an Allen wrench.
6
Screw the lamps into the sockets. Refer to the label on the socket for Max Wattage Information.
I :
NEC compliant junction
LED dimmer. Consult lamp manufacturer for
3
4
MOUNTING
PLATE
CAUTION RISK OF FIRE
This product must be installed in accordance with the
applicable installation code by a person familiar with the
construction and operation of the product and the hazards
involved.
Use minimum 90°c supply conductors.
FIXTURE BASE
SOCKET
5
SET SCREW
ALLEN KEY
1
W 1842
W 1842 B
-
LAMP
6
B
1.0
