INSTRUCTION MANUAL FOR PC63 CAGE
INSTRUCTION MANUAL
FOR
PC63 CAGE
ECN/DATE
CPN106833
16816-6/05
106 BRADROCK DRIVE
DES PLAINES, IL. 60018
(847) 299-1188
FAX: (847) 299-3061
ISSUE DATE: 15689-12/02
INSTRUCTION DRAWING NUMBER:
LPC63-1
P25-
Page 1 of 10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PC63 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for La Marche PC63 Series

  • Page 1 INSTRUCTION MANUAL FOR PC63 CAGE INSTRUCTION MANUAL PC63 CAGE ECN/DATE CPN106833 16816-6/05 106 BRADROCK DRIVE DES PLAINES, IL. 60018 (847) 299-1188 FAX: (847) 299-3061 ISSUE DATE: 15689-12/02 INSTRUCTION DRAWING NUMBER: LPC63-1 P25- Page 1 of 10...

  • Page 2: Personal Precautions

    LA MARCHE POWER CONVERSION EQUIPMENT SAVE THESE INSTRUCTIONS This manual contains important safety and operating instructions for the La Marche Power Conversion Equipment. Before using this equipment, read all instructions and cautionary markings on (1) unit, (2) battery, and (3) product using the battery.
  • Page 3 INSTRUCTION MANUAL FOR PC63 CAGE PREPARING TO CHARGE ♦ If necessary to remove the battery connections, always remove grounded terminal from the battery first. Make sure all loads are disconnected and unit is off, so as not to cause an arc. ♦...

  • Page 4: Receiving Instructions

    3. Call La Marche Mfg. For a RETURN MATERIAL AUTHORIZATION NUMBER. Failure to properly file a claim for shipping damages, or provide a copy of the claim to La Marche Mfg., may void warranty service for any physical damages reported for repair.
  • Page 5 INSTRUCTION MANUAL FOR PC63 CAGE Description: The PC63 Cage is intended to be installed in a protected environment. The cage can have several different combinations dependant as to what has been ordered. Either four A63s or two A63s and a TPCD, can be inserted in a PC63 cage.
  • Page 6 INSTRUCTION MANUAL FOR PC63 CAGE MODEL DC OUTPUT OF PC63 CAGE Wire Gauge guide for runs less then 10FT PC63-60-48V-130V 60A, 48V #8 from one Terminal Block #8 from both Terminal Blocks to a PC63-120-24V-130V 120A, 24V Termination Buss Bar #8 from both Terminal Blocks to a PC63-120-12V-130V 120A, 12V...

  • Page 7: Installers Information

    INSTRUCTION MANUAL FOR PC63 CAGE INSTALLERS INFORMATION The table below lists the a.c. and the d.c. minimum wire size requirements. At distances exceeding 10 feet, the d.c. wire size should be chosen to keep the voltage difference between the unit's terminals and the battery at less than 1/2 volt when the unit is fully loaded.

  • Page 8: Wire Gauge Table

    INSTRUCTION MANUAL FOR PC63 CAGE POWER CABLING FORMULAS WIRE GAUGE TABLE AREA AREA SIZE CIR. SIZE CIR. MILS MCM* MILS 1620 250000 2580 300000 4110 350000 6530 400000 10380 500000 16510 600000 26240 700000 41740 750000 52620 800000 66360 900000 83690 1000 1000000...
  • Page 9 INSTRUCTION MANUAL FOR PC63 CAGE General Maintenance Procedure Yearly 1. Blow out rectifier/inverter with a low-pressure air hose. 2. Make sure all connections are tight. 3. Perform a visual check on all internal components. 4. Check front panel meters and alarms for accuracy. 4th Year REPEAT ABOVE WITH THE ADDITION OF: 1.

  • Page 10: Manufacturer's Warranty

    Should the equipment require major replacement or repair, the equipment must be returned to the La Marche factory to have the inspections, parts, replacements and testing performed by factory personnel. Should it be necessary to return a piece of equipment to the factory, the customer or Sales representative must first obtain a RMA (Return Material Authorization) from the factory.
