Tvone CORIOmatrix Quick Start Manual

CORIOmatrix
This QuickStart Guide will show you how to start using the CORIO®matrix, a high quality modular video matrix router. Sixteen modular AV slots are available and can be populated as
inputs or outputs as needed. CORIOmatrix scaled output modules provide Up, Down and Cross conversion between a wide variety of analog and digital video formats.
For more advanced features, please refer to the User Manual available via the QR code at right or by navigating to http://tvone.com/CORIOmatrix-manual/.
Install
Unpack the unit and connect your video and audio inputs and outputs. Embedded audio switching is supported.
Connect your PC to the CORIOma
Connect the
1.
Install CORIOdiscover to your PC
from the inbox USB memory stick
or from the website:
http://tvone.com/CORIOmatrix-manual
Open the CORIOdiscover software
to find any units on your local
subnet
Select the appropriate CORIOmatrix
and click the Configure button to
change network settings as desired.
Click the Open button to conect via
your default browser to the web UI
on that CORIOmatrix.
2. Logging In
Once the CORIOmatrix is configured, if you don't use CORIOdiscover, you
can connect to the unit by typing its IP address into a web browser* .
Q trix : CSG-C3-340
a Windows (Vista, 7 or 8)-based discovery application, onto your PC. Download the latest firmware from http://tvone.com/tech_support_firmware.shtml.
configuration can only be done by integrated web UI .
mini
cable and turn on the unit via the ower w itch on the ear. The unit is ready to use when the LED on the front panel turns green
3. CORIOmatrix & CORIOmatrix mini W
After logging in (default username and password are "admin" and "adminpw"), you see the routing page.
*
Supported browsers
include current
versions of Chrome,
Firefox,, Safari, and
Internet Explorer.
For specifics, see
the manual.
The main areas are the Video Routing Page, Audio Routing Page, Settings, and Presets:
Video Routing
Audio Routing
Presets
You can operate in either Immediate or Synchronized mode. To save your settings, click Save in the bottom right corner of the window.
can switch between presets and make minor changes
Control Interface Overview
Use the grid to assign video inputs to video outputs and configure them. (See Video tab at top left.)
Use the grid to assign audio inputs to appropriate outputs and configure them. (See Audio tab at top left.)
Set up different presets within a configuration. Switch between presets on the fly.
Video and Audio Routing

Quickstart Guide

i
. N on-administrators
1.0 7
