Summary of Contents for Stima VP2 EVOLUTION XL
- Page 1 MANUALE DI ISTRUZIONI INSTRUCTION MANUAL MANUEL D' INSTRUCTION MANUAL DE INSTRUCCIONES ANLEITUNGS HANDBUCH VP/2 EVOLUTION VP2 EVOLUTION XL VP2 EVOLUTION 17.7...
-
Page 3: Table Of Contents
CONTENTS RECEIVING THE OVEN......................PAGE 24 PACKAGING...........................PAGE 24 WARNINGS..........................PAGE 24 INSTALLATION........................PAGE 25 ELECTRICAL HOOK UP......................PAGE 25 CONTROL PANEL........................PAGE 26 USE............................PAGE 27 PROGRAMMING........................PAGE 29 ROUTINE CLEANING......................PAGE 35 MAINTENANCE........................PAGE 35 TROUBLESHOOTING......................PAGE 36 THE CHEF'S SUGGESTIONS....................PAGE 36 TECHNICAL SPECIFICATIONS....................PAGE 37 DECLARATION OF CONFORMITY..................PAGE 38 SAFETY SYMBOLS ON THE OVEN..................PAGE 39... -
Page 4: Receiving The Oven
RECEIVING THE OVEN OPEN THE PACKAGING AND PERFORM THE FOLLOWING CHECKS: VERIFY THAT THE USER MANUAL IS PRESENT AND MAKE IT AVAILABLE TO THE OPERATORS. EVERY OPERATOR IS REQUIRED TO READ IT CAREFULLY, ESPECIALLY THE PART REGARDING SAFETY RULES, BEFORE OPERATING THE OVEN. MAKE SURE THAT THE DATA SHOWN ON THE PLATE LOCATED ON THE BACK OF THE OVEN IS COMPATIBLE WITH THE ELECTRICAL SYSTEM ON THE PREMISES. -
Page 5: Installation
INSTALLATION AND PUTTING INTO OPERATION MUST BE PERFORMED BY QUALIFIED PERSONNEL. THE OVEN MUST BE CONNECTED TO AN ADEQUATE OUTLET WITH A CAPACITY OF NOT LESS THAN 16A (25A VERSION VP2 EVOLUTION XL 220V) AND PROVIDED WITH A GROUND/EARTH CONNECTION. THE GROUNDING SYSTEM MUST CONFORM WITH THE LAW. -
Page 6: Control Panel
CONTROL PANEL MODELS: VP/2 EVOLUTION VP/2 EVOLUTION XL VP/2 EVOLUTION 17.7 TIMERS TIMERS BUTTONS BUTTONS RESET BUTTON RESET BUTTON POWER STANDBY BUTTONS BUTTONS UP AND DOWN PROGRAMMING BUTTONS... -
Page 7: Use
BEFORE USING THE OVEN, REMOVE THE PROTECTIVE FILM COVERING THE STEEL AND MAKE SURE THERE IS NO PACKAGING RESIDUE INSIDE THE COOKING CHAMBER. TURN ON AND LEAVE THE OVEN RUNNING FOR AT LEAST ONE HOUR BEFORE INTRODUCING FOOD. TURN ON THE OVEN BAKED ON SITE GENERAL OWN SWITCH (ON THE BACK NEAR 'THE POWER CORD IN THE MODEL "VP / 2 EVOLUTION";... - Page 8 THE OVEN IS READY TO BE USED (WE SUGGEST YOU WAIT AN ADDITIONAL 2 HOURS BEFORE INTRODUCING FOOD) WEAR OVEN MITTS AND USE HEAT RESISTANT UTENSILS WHEN PLACING FOOD IN THE OVEN. A SINGLE LEVEL CAN BE USED AT THIS POINT. IF A SINGLE LEVEL IS USED, WE SUGGEST YOU USE THE UPPER LEVEL.
-
Page 9: Programming
THE SET TIME WILL APPEAR ON THE DISPLAY. A BUZZER WILL SOUND WHEN THIS TIME HAS ELAPSED. RESET PRESS ONE OF THE BUTTONS IN THE EVENT OF ERROR STOP TO TURN STANDBY THE OVEN, PRESS THE BUTTONS TO TURN OFF THE OVEN PUT ON "0" THE GENERAL SWITCH SITE ON THE MACHINE PROGRAMMING THE OVEN IS FACTORY PROGRAMMED AS FOLLOWS: UPPER TEMPERATURE.. - Page 10 TO CHANGE THE UPPER LEVEL TEMPERATURE TURN ON THE OVEN START PRESS THE UPPER BUTTON RESET PRESS AND HOLD DOWN THE LEFT BUTTON FOR 3 SECONDS THE FOLLOWING APPEARS ON THE DISPLAY: DOWN PRESS THE BUTTONS TO SET THE REQUIRED TEMPERATURE...
- Page 11 RESET PRESS THE LEFT BUTTON TO SAVE THE SET VALUE AND RETURN TO NORMAL USE NB: A TEMPERATURE BETWEEN 30 DEGREES / 450 DEGREES CAN BE SET. TO CHANGE THE LOWER LEVEL TEMPERATURE TURN ON THE OVEN START PRESS THE BOTTOM BUTTON RESET PRESS AND HOLD DOWN THE RIGHT...
- Page 12 DOWN PRESS THE BUTTONS TO SET THE REQUIRED TEMPERATURE RESET PRESS THE RIGHT BUTTON TO SAVE THE SET VALUE AND RETURN TO NORMAL USE NB: A TEMPERATURE BETWEEN 30 DEGREES/ 450 DEGREES CAN BE SET. TO CHANGE COOKING TIMERS TURN ON THE OVEN 2 STOP PRESS THE BUTTONS...
- Page 13 WAIT UNTIL THE DISPLAY TURNS OFF PRESS THE NUMBERED TIMER BUTTON TO BE CHANGED AND HOLD IT DOWN FOR 3 SECONDS THE FOLLOWING APPEARS ON THE DISPLAY EXAMPLE LEFT BUTTON DOWN TO SET A NEW TIME, PRESS THE ARROW FOLLOW THE SAME STEPS FOR THE OTHER BUTTONS . START PRESS ONE OF THE BUTTONS TO SAVE AND EXIT PROGRAMMING...
- Page 14 TO DISPLAY THE NUMBER OF TIMES THE OVEN WAS USED TURN ON THE OVEN . STOP PRESS THE BUTTONS WAIT UNTIL THE DISPLAY TURNS OFF PRESS AND HOLD DOWN THE ARROW FOR 3 SECONDS THE NUMBER OF TIMES BOTH LEVELS WERE TURNED ON AND USED WILL BE DISPLAYED STOP PRESS TO EXIT PROGRAMMING AND RETURN TO NORMAL USE.
-
Page 15: Routine Cleaning
ROUTINE CLEANING WAIT UNTIL THE OVEN HAS COOLED (BOTH COOKING CHAMBER TEMPERATURES UNDER 50 DEGREES). UNPLUG THE POWER CORD DO NOT USE RUNNING WATER, ABRASIVE OR ACIDIC SUBSTANCES TO CLEAN THE OVEN. CLEANING MUST BE THOROUGH AND THE OVEN MUST BE CLEANED AFTER EACH USE . MAINTENANCE REPLACE THE FILTER BASED ON OVEN USE. -
Page 16: Troubleshooting
TROUBLESHOOTING 1. THE MACHINE DOES NOT TURN ON. MAKE SURE ELECTRICITY REACHES THE SOCKET WHERE THE MACHINE POWER CORD IS PLUGGED IN. MAKE SURE THE LIGHTED SWITCH ON THE BACK IS LIT AND IN THE ON POSITION. 2. THE OVEN BLOWS A FUSE IN THE FUSE BOX AFTER RUNNING FOR 10 MINUTES OR MORE. THIS IS CERTAINLY NOT AN OVEN FAULT. -
Page 17: Technical Specifications
TECHNICAL SPECIFICATIONS OVEN VP/2 EVOLUTION WIDTH........63 CM DEPTH........55 CM HEIGHT.........49 CM WEIGHT.........46 KG VOLTAGE.......220 V TEMPERATURE.....MAX 450 °C MAXIMUM POWER....2,55KW OVEN VP/2 EVOLUTION 17.7 WIDTH........67 CM DEPTH........58 CM HEIGHT.........50 CM WEIGHT.........46 KG VOLTAGE.......220 V TEMPERATURE.....MAX 450 °C MAXIMUM POWER....3,5 KW OVEN VP/2 EVOLUTION XL WIDTH........88 CM DEPTH........60,5 CM... -
Page 18: Declaration Of Conformity
DECLARATION OF CONFORMITY EUROPEAN STANDARDS S.T.I.M.A. SRL represented by its legal representative Mr. Fabrizio Venturini, with headquarters in Agliana via Prato nr. 23/25/27 Declares that the new machine described below: Model : VP/2 EVOLUTION VP/2 EVOLUTION XL 2-CHAMBER PIZZA OVEN VP/2 EVOLUTION 17.7 YEAR OF MANUFACTURE AND SERIAL NUMBER AS LISTED ON THE MACHINE PLATE. -
Page 19: Safety Symbols On The Oven
SIMBOLI DI SICUREZZA PRESENTI SUL FORNO L'utilizzatore ha l'obbligo di controllare che i simboli non siano danneggiati SAFETY SYMBOLS ON THE OVEN The user is obliged to check that the symbols are not damaged SYMBOLES DE SÉCURITÉ SUR LE FOUR L'utilisateur est tenu de vérifier que les symboles ne sont pas endommagés SÍMBOLOS DE SEGURIDAD EN EL HORNO El usuario está...
