Summary of Contents for Eno Scientific WELL SOUNDER WS2010 PRO
- Page 1 STATIC WATER LEVEL MEASUREMENT WELL SOUNDER WS2010 / WS2010 PRO USER MANUAL For Sales & Service Contact 2650 E. 40th Ave. • Denver, CO 80205 Phone 303-320-4764 • Fax 303-322-7242 1-800-833-7958 www.enoscientific.com www.geotechenv.com Eno Scientific Well Sounder 2010/2010 PRO Page 1...
- Page 2 Eno Scientific 1606 Faucette Mill Rd Hillsborough, NC 27278 www.enoscientific.com 910-778-2660 Copyright Notice Copyright © 2014 Eno Scientific, Hillsborough, NC 27278, USA. All rights reserved. Part number: 128-2026-16 Eno Scientific Well Sounder 2010/2010 PRO Page 2...
-
Page 3: Table Of Contents
INTERPRETATION OF DATA..................25 MODBUS COMMUNICATIONS..................26 FLOW METER OPTION....................30 ANALOG OUTPUT OPTION..................31 MAINTENANCE......................31 FREQUENTLY ASKED QUESTIONS................32 TROUBLESHOOTING....................35 ERROR CODES......................36 SPECIFICATIONS......................37 ADDITIONAL NOTES....................38 WARRANTY AND SERVICE..................39 Eno Scientific Well Sounder 2010/2010 PRO Page 3... -
Page 4: Product Overview
ID. The PRO version also offers enhanced power save functions such as Auto-off and the ability to provide an alarm output, a 0-5 volt analog voltages as well as a 4-20 ma current loop output. Eno Scientific Well Sounder 2010/2010 PRO Page 4... - Page 5 Other features can be found by pressing the SET or DISP buttons. Several accessories are available for the Well Sounder 2010 PRO which can be found on our website at www.enoscientific.com. Eno Scientific Well Sounder 2010/2010 PRO Page 5...
-
Page 6: Quick Start Guide
We encourage you to read the frequently asked questions section. They really are frequently asked. Also, visit our website www.enoscientific.com for the latest manual and installation tips. Eno Scientific Well Sounder 2010/2010 PRO Page 6... -
Page 7: Cautions
UNDESIRED OPERATION. NOTE: THE GRANTEE IS NOT RESPONSIBLE FOR ANY CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. Eno Scientific Well Sounder 2010/2010 PRO Page 7... - Page 8 à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée quivalente (p.i.r.e.) ne dépassepas l'intensité nécessaire à l'établissement d'une communication satisfaisante. Eno Scientific Well Sounder 2010/2010 PRO Page 8...
-
Page 9: Background - How It Works
Well Sounder leaving the main wave a little weaker. A complete obstruction like the surface of the water, reflects the entire remaining wave. Most common obstructions like wires and tubes and pipe couplings do not reflect enough of the wave to cause a Eno Scientific Well Sounder 2010/2010 PRO Page 9... - Page 10 When set to 9ft, the depth would read 12. When set to 14ft, it would read 18 etc. In this case, it may be helpful to leave a small leak at the probe to help dissipate the pulse. Eno Scientific Well Sounder 2010/2010 PRO Page 10...
-
Page 11: Operation
DEFAULT DISPLAY: While the display shows depth on the top line, press the UP or DOWN button to scroll through additional information on the second line. The following information may be available depending on options installed and enabled: Eno Scientific Well Sounder 2010/2010 PRO Page 11... - Page 12 1. Product Info – displays model number, version and serial number. 2. Unit ID – user settable well ID number. 3. Sounder Enable – enables the depth sounding features. 4. Range Min – sets the minimum range to detect. Eno Scientific Well Sounder 2010/2010 PRO Page 12...
- Page 13 PROBE TEMP– displays the temperature measured by the probe. This temperature is used to automatically compensate sound speed variations due to temperature in the upper part of the well. Eno Scientific Well Sounder 2010/2010 PRO Page 13...
- Page 14 ID number, the temperature, the battery level, the signal gain and the error code (if any). More data is available when the log is dumped through the RS232 connection. Other points are displayed by Eno Scientific Well Sounder 2010/2010 PRO Page 14...
- Page 15 The distance error is fairly small for variations in temperature, about 1% for a 10 ºF (5.6 ºC) temperature error. Eno Scientific Well Sounder 2010/2010 PRO Page 15...
- Page 16 OFFSET – sets the offset of the probe position from ground level. If for example, the probe is inserted into a well cap on a well casing that extends 30” above the ground. Then enter 30” for the offset. This will automatically be deducted from the depth Eno Scientific Well Sounder 2010/2010 PRO Page 16...
- Page 17 OUTPUT – enables the output features on newer models of the 2010PRO. These outputs are accessible with an optional breakout adapter and include an alarm output, Eno Scientific Well Sounder 2010/2010 PRO Page 17...
- Page 18 Normal or Power Save. When logging data and the Power Save function is activated, the unit goes into sleep mode between logging periods. Battery life can be extended by more than 6 times using this function. The 2010 PRO Eno Scientific Well Sounder 2010/2010 PRO Page 18...
-
Page 19: Logging
ENABLED. Then press the SET button again to show the log period screen. Press the UP or DOWN button to set the log interval in minutes. If the log period is set Eno Scientific Well Sounder 2010/2010 PRO Page 19... -
Page 20: Usb Communications
SCADA system or remote readout. A 9 pin D connector on the side of the unit allows the unit to connect to a computer or other Eno Scientific Well Sounder 2010/2010 PRO Page 20... -
Page 21: Remote Serial Operation
RS232 device using a standard straight through serial cable. A simple serial to USB adapter is available from Eno Scientific or most computer stores to use with laptops without serial ports. The default serial configuration on the Well Sounder is 19200 baud, 8 data bits, 1 stop bit, no parity, and no flow control. - Page 22 (decimal point optional), and <ret> indicates a return. <ret> send current data a0<ret> alarm off a1<ret> low alarm on a2<ret> high alarm on a3<ret> both alarms on ah[iiii] <ret> set high alarm level al[iiii] <ret> set low alarm level Eno Scientific Well Sounder 2010/2010 PRO Page 22...
- Page 23 4 – 9600 5 – 14400 6 – 19200 7 – 38400 8 – 57600 tm[hh:mm:ss] <ret> set time td[yy/mm/dd] <ret> set date u0<ret> set english units (ft) u1<ret> set english units (ft in) Eno Scientific Well Sounder 2010/2010 PRO Page 23...
-
Page 24: Downloading Data
8 – Press “d<enter>” on the computer keyboard to start the download. The last data line will be followed by END. 9 – Close the log file as described in item 6. Eno Scientific Well Sounder 2010/2010 PRO Page 24... -
Page 25: Interpretation Of Data
168 points have been used out of 14975. Example: WS2k > ? Mod #WS1100-1023 Ver # 1018 Ser #080628015 ID #001 t2008/07/21 10:12:33 l0 lp15 lm 0.30 s0 r 700.00 o 0.00 p0 u0 Eno Scientific Well Sounder 2010/2010 PRO Page 25... -
Page 26: Modbus Communications
The Well Sounder can be configured for a modbus network by pressing the SET button repeatedly until the display reads RS232. Then press the UP button until Modbus is shown. Press the SET button again to show the serial settings, the baud rate, number Eno Scientific Well Sounder 2010/2010 PRO Page 26... - Page 27 32 bit Float 1018 Error Code 32 bit Integer 1020 Gain Pulse 32 bit Integer 1022 Gain Echo 32 bit Integer 1024 Binary Time 32 bit Integer 1026 Binary Date 32 bit Integer Eno Scientific Well Sounder 2010/2010 PRO Page 27...
- Page 28 2070 Sound Speed B 32 bit Float 2072 Sound Speed C 32 bit Float 2074 Battery Scale 32 bit Float 2076 Pulse Width 32 bit Integer 2078 Fing strt 32 bit Integer Eno Scientific Well Sounder 2010/2010 PRO Page 28...
- Page 29 Fact test T2 32 bit Float 2108 Fact test T3 32 bit Float 2110 Fact test Bat 32 bit Float 2112 Fact test RTC 32 bit Float 2114 Modbus Config 32 bit Integer Eno Scientific Well Sounder 2010/2010 PRO Page 29...
-
Page 30: Flow Meter Option
The scale factor is used to calculate how much flow has passed for each count. The Eno Scientific flow meters output full pulses and have scale factors like .0057 gallons per pulse for the 1” flow meter. So since the flow meter outputs full pulses the entered scale factor should be half of that or .00285 gallons pre count. -
Page 31: Analog Output Option
Then replace the screws and tighten to snug being careful not to strip the screws. Eno Scientific Well Sounder 2010/2010 PRO Page 31... -
Page 32: Frequently Asked Questions
Well Sounder to detect. In this case, the Well Sounder will track the descending water level until it gets to the perforations and then stick at the start of the exposed perforations as the water level continues to descend. Eno Scientific Well Sounder 2010/2010 PRO Page 32... - Page 33 A: Hand dug wells are often fairly large and irregular, and as such may cause problems for the Well Sounder due to multiple or weak reflections. Some work and some do not. However, in any difficult to measure well, a small tube can be installed specifically for Eno Scientific Well Sounder 2010/2010 PRO Page 33...
- Page 34 45ft, the depth will jump to 60ft etc. In many cases, after the the pulse has passed the nearby stronger reflections, the stronger reflection from the water will dominate and the depth will jump up to the water level. Eno Scientific Well Sounder 2010/2010 PRO Page 34...
-
Page 35: Troubleshooting
TROUBLESHOOTING Eno Scientific Well Sounder 2010/2010 PRO Page 35... -
Page 36: Error Codes
1 - Probe error 2 - Low Alarm 4 - High Alarm 8 - Low signal And the left digit: 1 - High Signal 2 - USB Connected 4 - R14 8 - R15 Eno Scientific Well Sounder 2010/2010 PRO Page 36... -
Page 37: Specifications
Flow meter input (with optional adapter) – TTL level transition counting. Temperature sensor input Serial port OUTPUTS: Serial port USB (2010 PRO only) Analog 0-5 volt, 4-20 ma, 0 or 5 volt alarm (with optional adapter) Eno Scientific Well Sounder 2010/2010 PRO Page 37... -
Page 38: Additional Notes
The maximum range is limited by the maximum time during which the echo is monitored, and the strength of the echo signal. Uncased wells drilled through porous material can attenuate the signal faster than the rated distance, making detection impossible. Eno Scientific Well Sounder 2010/2010 PRO Page 38... -
Page 39: Warranty And Service
WARRANTY AND SERVICE Eno Scientific warrants to the user that all products manufactured by Eno Scientific, will be free from defects in workmanship and materials for 1 year from the date of shipment. Eno Scientific warrants to repair or replace any such defective equipment or part... - Page 40 Eno Scientific Well Sounder 2010/2010 PRO Page 40...
