- Page 1 Accumulators Charging & Gauging Units FPK / FPS Operating Manual 1.877.GO.HYDAC www.HYDACusa.com 1.888.99.HYDAC www.HYDAC.ca...
- Page 2 O-ring (where applicable) (where applicable) Allen Wrench 6 mm (to be used to crack open M8 SHCS. Valve T handle on FPK Charging is not robust enough to overcome recommended torque) seal cap Socket Head Cap Screw (M8) O-ring...
-
Page 3: Tools Required
= gas precharge pressure at 0,T2 version 4, hand tighten. Close manual bleed maximum operating temperature valve on the FPK unit hand tight. Connect FPK unit to adapter FPK/SB by screwing cap nut onto the adapter; hand tighten. Charging & Gauging Units... - Page 4 (see page 4) Turn T-handle counter clockwise 3 full turns. Proceed to “Filling”. Pressure Release FPK Unit (with adapter FPK/SB) With the appropriate charging and gauging Turn T-handle clockwise 3 full turns. unit attached as previously described, Proceed to “Filling”.
- Page 5 100 psi is reached, the charging rate can Unscrew the charging and gauging unit increase. Charging too quickly may damage from the gas valve. Note: For FPK unit with the accumulator. adapter FPK/SB it may be necessary to Note: The gauge registers the line pressure,...
- Page 6 00610004 Manual Bleed Valve 00236445 O-Ring - FPS 00626488 O-Ring - FPK 00601049 2.5m Hose 00236514 4m Hose 00236515 10m Hose 00373405 ADAPTER G4 02068737 ADAPTER A3 (FPK/SB) 00291533 O-Ring - ADAPTER A3 (FPK/SB) 00601964 6 Charging & Gauging Units...
- Page 7 M28x1.5 M28x1.5 M28x1.5 M16x1.5 M8x1 PN 00361605 PN 02108819 PN 02128849 M28x1.5 M28x1.5 M28x1.5 5/8-18UNF 7/8-14UNF G3/4A A3 (ADAPTER FPK/SB) PN 00291533 PN 02110629 PN 03018210 M28x1.5 M28x1.5 M28x1.5 G1/4 M16x2 7/8-14UNF PN 00291536 PN 02124524 PN 03930191 M28x1.5 M28x1.5 M28x1.5...
- Page 8 A6x10 seal ring A6x10 Japan China SW 32 SW 32 SW 32 SW 32 Charging Hoses Germany Poland SW32 Others M14x1.5 W24.32x1/14" © Copyright 2014 HYDAC CORPORATION • FPK/FPS Operating Manual PN#02068202 • ACU1403-1605 SW32 1.877.GO.HYDAC www.HYDACusa.com 1.888.99.HYDAC www.HYDAC.ca...
