tecpro
b y C a n f o r d
Product Code 27-511 BP511 Single Circuit beltpack (Male and Female XLR-3 Connectors, with loop through)
Product Code 27-523 BP523 Dual Circuit beltpack (Female XLR-3 Connectors, no loop through)
Product Code 27-525 BP525 Dual Circuit beltpack (Male and Female XLR-5 Connectors, with loop through)
Product Code 27-531 BP531 Single Circuit beltpack with vibration alert (Male and Female XLR-3 Connectors with loop through)
Product Code 27-543 BP543 Dual Circuit beltpack with vibration alert (Female XLR-3 Connectors, no loop through)
Product Code 27-545 BP545 Dual Circuit beltpack with vibration alert (Male and Female XLR-5 Connectors, with loop through)
2
TECPRO BELTPACKS
USER GUIDE
BP511
&
BP531
Canford Audio Plc
Crowther Road
www.canford.co.uk
02-454 (Issue 2) 10.09.
BP523
&
BP543
Washington
Tyne and Wear
NE38 0BW
BP525
&
BP545
Advertisement
Related Manuals for Canford TECPRO 2 BP511
Summary of Contents for Canford TECPRO 2 BP511
- Page 1 Product Code 27-543 BP543 Dual Circuit beltpack with vibration alert (Female XLR-3 Connectors, no loop through) Product Code 27-545 BP545 Dual Circuit beltpack with vibration alert (Male and Female XLR-5 Connectors, with loop through) Canford Audio Plc Crowther Road Washington...
-
Page 2: Basic Operation
CONNECTING THE BELTPACK TO THE SYSTEM BP511 and BP531 This single circuit beltpack is connected to the system via the available male and female XLR 3 pin connectors. By convention the female connector is used as the input and the male connector as the output enabling the cabling to be 'looped through' to the next station, if required. -
Page 3: Programmable Options
PROGRAMMABLE OPTIONS All settings revert to default when power is removed. Default settings 1. Call alert tone ON/OFF - ON. 2. Bright or dim green LED’s - bright. 3. Vibration mode ON/OFF (Duplicates Call LED and will respond to a Call signal when the Call LED is suppressed in ‘dim’... -
Page 4: Technical Specification
MISCELLANEOUS Circuit Enable/Disable BP523 and BP543 If only one circuit is connected, then only this circuit is active. On the unused circuit, the line amplifier is dis- abled and the Mic LED does not light if the Mic key is pressed. BP525 and BP545 With XLR-5 connectors, a given circuit is only active if its +24 volt line is powered. - Page 5 4-pin XLR wiring for headsets with an impedance of more than 100ohms per ear. DIAGRAM 1 Page 4...
- Page 6 4-pin XLR wiring for headsets with an impedance of less than 100ohms per ear. DIAGRAM 2 Page 5...
- Page 7 NOTES...
