Summary of Contents for e-Taxfree Nordic Oy TF1 E-POS MINI
- Page 1 E-TAXFREE NORDIC OY E-POS MINI Quick Reference Guide Edition: Aug 2015 Version: 1.2...
- Page 2 E-POS MINI TF1...
-
Page 3: Packing Checklist
E-TAXFREE NORDIC OY Packing Checklist Confirm that all the following items are contained in the carton. If any item is missing or damaged, Contact E-Taxfree Nordic Oy for replacement. Quick Reference Guide √ √ AC Adapter √ E-POS MINI √... - Page 4 E-POS MINI TF1 I/O Interface Port Description Port Description Power on/off POWER Power Button DC 5V / 3A Switch (DC Input) Power Cord 2D scanner Power cable locked scanner Mounting (Motorola engine) 2 x USB 2.0 Type A Lock Security Lock That way you can lock the security cable to the E-POS MINI case, and loop the cable other end around a fixed object.
- Page 5 E-TAXFREE NORDIC OY Appearance Side View Front View MRZ scanner 5" TFT LCD Display screen 2D scanner (Motorola engine) Base Security Lock Speaker Side View Tilt angle 55 ~ 10 degree(45∘Default)
-
Page 6: Power On For The First Time
E-POS MINI TF1 USING YOUR E-POS MINI For first-time use, you need to Plug your E-POS MINI Connect the power connector and plug the AC adapter side into any AC outlet. Step 1 Choose the sleeve size of the power cord retainer based on the thickness of the cord. -
Page 7: Using The Touch Screen
E-TAXFREE NORDIC OY USING THE TOUCHSCREEN Your E-POS MINI uses a touch screen for selecting items and entering information. Use your finger to tap the screen. Tap: Touch the screen once to open items and select options. Drag: Hold your finger on the screen and drag across the screen to select text and images. - Page 8 E-POS MINI TF1 MRZ passport scanner...
- Page 9 E-TAXFREE NORDIC OY Scanner Skew, Pitch, and Roll Measured on a 20 mil Code93 and QR code symbol at a distance of 5 inches. Tolerance for skew and pitch is reduced at extreme ends of the working range. lists the typical and guaranteed distances for selected barcode densities.
- Page 10 E-POS MINI TF1 Specification Model Name System Processor MTK MT6582V Display Size 5" TFT LCD Resolution 960 x 540 pixels Touch Panel Capacitive OS Support Android 4.4 Interface 2(5V/0.2A) Wired LAN 802.11b / g / n Micro Sim Card - Yes Speaker 2D Scanner Motorola SE-4500DL 2D Scanner...
- Page 11 E-TAXFREE NORDIC OY Federal Communications Commission (FCC) Statement The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment.
- Page 12 E-POS MINI TF1 Bluetooth This equipment manipulates the Bluetooth V4.0 and low energy (BLE) system that operates at 2402 MHz ~ 2480 MHz with 79 channels available, The modulation type have GFSK, 8-DPSK and DQPSK. It also features a WLAN coexistence interface controller, and integrated Class 1.5 Power Amplifiers (PAs) to address the needs of mobile devices that require minimal power consumption and compact size.
- Page 13 E-TAXFREE NORDIC OY...
- Page 14 E-POS MINI TF1 E-TAXFREE NORDIC OY Tammasaarenlaituri 3 | 00180 Helsinki | Finland Phone: +358 10 5044 040 www.e-taxfree.com...
