Page 2
F8530, F8530P (Packer) External Lever Handle. F8730-70/115K Used for door blades including gasket between 70mm and 115mm thick. F8730-115/160K Used for door blades including gasket 115mm and 160mm thick. Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 3
1. Due to the varying density of wall panel types used in Australia, Track Rail CRH Australia STRONGLY recommends that an aluminium Support Rail is securely fixed to the panel wall and then the Track Rail Brackets are secured into or through the Support Rail.
Roller + trolley RH Roller + trolley LH Door bracket/Door RH Door bracket/Door LH Trolley cover Complete roller assembly RH (1) Complete roller assembly LH (1) Rail end cap (2) Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 6
Door size construction should also allow for the Fermod Gasket supplied in the kit. F8511 Frame Gasket - 35mm Height, F250 Floor Gasket - 35mm Height. Trolley Assemblies Lever Handle anchoring point Left Hand Opening Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 7
Kit” which will include the extra run of frame gasket. Inside Face of Door Blade NOTE: Negative temperature means doors operating below zero Positive Temperature Configuration Negative Temperature Configuration degrees celsius Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 8
Purchase a “Negative Temperature Kit” which will include the extra run of floor gasket and fixing profile. Negative temperature floor gasket configuration Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 9
X= Total door blade width. Closing Example: Side If the total door blade width Opening Side is 1600mm the cut floor guide rail length is 1660mm. Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 10
Step 4. Attach the floor guide rail to the front Closing Side face of the door blade. Opening Side Ø5 X+60 Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 11
Gasket. Using a different gasket may require adjustment. Note: Be precise on your locations measuring from the inside of the door blade, as there is little horizontal adjustment available on the hanging brackets. Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 12
45mm. “X” equals the total door blade width. Example: If the total door blade width is 1600mm, 2 lengths need to be cut at 1555mm. (1600 - 45) Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 13
• Opening side, push the clamp so all parts are in contact and tighten. • Slide the rail stops onto each end of the rail and temporarily tighten. Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 14
• Measure up 149mm from the top of the clear opening & this is the location point of the bottom centre mounting hole. • You can now locate your support rail holder brackets. Fix the support rail to the wall ensuring it is level. Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 15
Y = Door height. H= Clear opening height. Closing Side Step 10. Mark and drill the fixing holes for the rail brackets. Bottom centre mounting hole Top mounting holes Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 16
CLOSING SIDE This will affect the performance of the door. In this case, loosen the top bracket screws and Fig.B adjust the top rail outwards. Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 17
Fig.b R + 1 = 51mm Note: If fixing through floor tiles drill a 5mm pilot hole before inserting the Masonary Anchors other wise you may damage the tile. Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 18
See Fig A & B on the next Loosen screws C 1/2 turn. page. Tighten or loosen screw B A25 A24 Lock screw C 5. Loosen A for horizontal adjustment then tighten. Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 19
Fig.A. Opening side floor guide in the open position. The guide allows for 7mm +/- adjustment. Fig.B. Closing side floor guide in the closed position Gasket Fig.B Gasket (Sealed but not squashed) Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 20
1. Cut to size and attach the rail upper cover (A10). This is a dirt and hygiene protection feature 2. Attach the 2 x rail end covers. (A26) Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 21
Step 18. Adjust the opening and closing side stops. 1. Adjust the stops and tighten the screws as shown. X = Width of door. X-15 Closing Side Opening Side Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 22
To comply to Australian Standards the area where the hand grips the handle should be 1000mm - 1100mm from the floor. See drawings for optimal anchoring locations. 62mm 40mm Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 23
Step 19 Continued. DOOR Assembly/Door RH Opening Assembly / Door LH Opening Affix security stickers Upper Housing Lower Housing Assembly/Door RH Opening DOOR Assembly/ Door LH Opening screws Ø6 P3bis Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 24
15mm Lever Handle Packer Strike Strengthening Plate 15mm Packer 80mm Frame Strengthening Plate Fix plate with surf mist rivets or self drilling screws. Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 25
Step 19 Continued. Attach the internal lever handles. Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 26
This is available as an ad- ditional item to the standard kit, stock code F8530P. Failure to install the packer may mean the internal lever handle will not connect with the strike. Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 27
2. Fix the lever handle with the screw supplied View on internal side of door! Left hand external Right hand external opening door opening door You can see arrows once lever assembled Maximum Torque 15Nm Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 28
Step 19 Continued 1. Mounting of the lever 2. Mounting of the strike. Ø8mm DOOR Screws Ø6mm (Not supplied) FRAME Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Maintenance must be carried out by qualified staff. When replacing a component, choose the right component from the manufacturer’s after sales service, and respect the instructions of the differ- ent sections in this manual. Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Fissures or missing plastic parts Floor gasket When black dust on floor or quarterly Cut in rubber Frame gasket When black dust on floor or quarterly Cut in rubber (especially in corners) Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
Page 31
For enquiries, please e-mail info@crh.com.au or call us at 1300 274 287 Fermod Floor Guided Sliding Door Hardware Kits - F2156 Installation Guide www.crh.com.au...
