Installation Instructions for Bike Fixtation Public Toolbox
Manual RevB
Space Setbacks:
The Public Toolbox is very versatile in where it can be installed. We recommend that it is placed in a
location that allows a bicycle to access it either perpendicular or horizontal to the wall. See Figure 1
below. It is possible to mount a pump or wheel chock within this setback region.
Advertisement
Table of Contents
Summary of Contents for Bike Fixtation Public Toolbox
- Page 1 Space Setbacks: The Public Toolbox is very versatile in where it can be installed. We recommend that it is placed in a location that allows a bicycle to access it either perpendicular or horizontal to the wall. See Figure 1...
- Page 2 Figure 1: Optimal setback options Typical Tools Needed for Installation Drill and drill bits Phillips Screwdriver Mounting Hardware (location dependent) Penta Nut Socket (included) 3/8” drive ratchet Marker or Pencil Level Tape Measure Wall Mounting or Vending Machine Mounting 1. Identify mounting location. Be sure to follow setbacks. The base of the toolbox should be mounted greater than 55"...
- Page 3 d. If installing into a stud wall, it is possible to use a #14 wood into 1 stud and toggle anchors into the other 2 holes that do not line up with a stud. 3. Once the back plate is secured, load the tools to the front cover as shown. 4.
- Page 4 5. Install and tighten penta nuts. Be careful not to over tighten. Optional Strike Plate 1. Locate the strike plate directly below the toolbox at a distance of 2” (5cm) off the floor. 2. If mounting to sheet metal, we recommend using #14 sheet metal screws no longer than 3/4" (20mm).
