CLOG500
User Manual
ISA – Intelligent Sensing Anywhere
Rua Pedro Nunes, Edifício D
3030-199 Coimbra, Portugal
Phone: +351 239 791 090
Fax: +351 239 791 099
Email: info@isasensing.com
http://www.isasensing.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLOG500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Intelligent Sensing Anywhere CLOG500

  • Page 1 CLOG500 User Manual ISA – Intelligent Sensing Anywhere Rua Pedro Nunes, Edifício D 3030-199 Coimbra, Portugal Phone: +351 239 791 090 Fax: +351 239 791 099 Email: info@isasensing.com http://www.isasensing.com...
  • Page 2 Artur Vieira Added option for variant EXC5_20XY 03/09/2014 V0.02 possibilitie to have possibilitie to have 2 Artur Vieira sensors. 18/09/2014 V1.0 Revision Ester Soares 27/01/2015 V1.01 Changes for FCC certification Artur Vieira 02/03/2015 V2.00 Revision Ester Soares CLOG500 User Manual...
  • Page 3: Table Of Contents

    4 Maintenance ................................4 5 Typical Installation procedure ..........................4 6 Sensor connection ..............................5 6.1 CLOG500 supplied with external cable ....................6 7 Placing the CLOG500 ............................. 6 7.1 Attaching the CLOG500 ..........................6 7.1.1 Using glue to attach......................... 7 7.1.2 Using cable ties to attach ......................
  • Page 4: General Information

    CLOG500 1 General Information The CLOG500 is a multi-purpose autonomous (GSM/CDMA/GPRS based, battery powered) remote management system providing data logging, automatic meter reading and alarms, certified to be used under potential explosive atmospheres. Collected and stored data is sent to a central server via GSM, through SMS or TCP, with a configurable frequency from several times a day to one time per week.
  • Page 5: Fcc Part 15 Compliance

    Consult the dealer or an experienced radio/TV technician for help.  You may also find helpful the following booklet, prepared by the FCC: "How to Identify and Resolve Radio-TV Interference Problems." This booklet is available from the U.S. Government Printing Office, Washington D.C. 20402. CLOG500 User Manual...
  • Page 6: Rf Exposure Information

    These instructions must be kept and followed throughout the life of the equipment. Never open the equipment when a potential explosive atmosphere may be present. POTENTIAL ELECTROSTATIC CHARGING HAZARD. CLEAN ONLY WITH DAMP CLOTHS. Only use approved batteries. Check other warnings in this manual (always marked with CLOG500 User Manual...
  • Page 7: Maintenance

    For version that only contains the ISM Band transceiver the only necessary steps are the sensor connection, equipment placement and activation. 1) Connect the sensor to the CLOG500 (see section 6). Some models may already have this connection. 2) Position the equipment next to the target (gas tank gauge, pulse meter, etc) and attach it using the base of the equipment (see section 7).
  • Page 8: Sensor Connection

    (max length= 3 m), or any sensor / digital switch which are compatible with the equipment. The sensor must already have the correct plug to connect to the CLOG500. The sensor connector is illustrated in the following picture: Figure 1 - Sensor connector location.
  • Page 9: Clog500 Supplied With External Cable

    To attach the equipment, it is recommended to use glue to fix the enclosure to the tank or use cable ties. The next Figure shows an example of how to correctly attach the CLOG500 to a gas tank hook with cable ties or glue.
  • Page 10: Using Glue To Attach

    Brake Cleaner (Ref: 08901087) 7.1.1 Using glue to attach 1. In case of fixation by glue, the user should clean the tank surface to remove dirt and degrease from the area where is going to apply glue: CLOG500 User Manual...
  • Page 11 2. Next, apply glue to the base that is going to be fixed in the tank and attach to the tank. Apply sufficient glue to provide a good fixation. Figure 8 - Base fixation. 3. Remove any glue excess. 4. Wait some minutes to allow the glue to fix. 5. Hook the CLOG500 in the base. CLOG500 User Manual...
  • Page 12: Using Cable Ties To Attach

    CLOG500 Figure 9 – CLOG500 in the final position. 7.1.2 Using cable ties to attach 1. Attach the base to a pipe or some other acceptable place using cable ties. Figure 10 - Fixation of the base. 2. Hook the CLOG500 in the base.
  • Page 13: Possible Scenarios

    The installation attaching option should be based on tank type. Equipment should always be placed in a vertical position when possible. The CLOG500 must be conveniently placed on a solid area (not in places that can move or have mechanical shock, for example covers, doors or fences), safe from flooding and particular attention should be paid to installation in totally metallic boxes, due to the effect of the Faraday cage.
  • Page 14: Equipment Activation

    8 Equipment activation 8.1 Passing the magnet to activate In order to activate the CLOG500 the user must have a magnet. The location to wave the magnet over is illustrated in the following picture. In the CLOG500 the magnet is on the opposite side from the sensor connection.
  • Page 15 CLOG500 Figure 13 - Location of the red and green LED on the CLOG500. Equipment that only have the ISM Transceiver will only have the RED LED. Visual indicator Status Observations Modem OFF Always ON Modem ON, waiting for GSM Network registration...
  • Page 16: Equipment Information

    Table 2 - Visual Indicators description for equipment with only ISM Band Transceiver. The CLOG500 only accepts the installation SMS if both red and green LEDs are flashing. If the equipment receives an installation SMS when the red LED is OFF, the equipment will respond with an SMS error.
  • Page 17: Sensors Connect Through Radio Device

    10 Tips and Tricks Here are some useful tips and tricks for CLOG500 installer: For level sensors use channel 1 to 2 because the CLOG500 sends instant data to  these channels. Instant data is very useful for level sensors.
  • Page 18  the SMS (delivery report). The CLOG500 has a limit to the number of SMS (for each type of SMS) it can send  each day. In case the limit is reached, the installer can reset the counter in order to receive an SMS from the CLOG500.
  • Page 19 A channel was incorrectly  Send an installation SMS with one dash instead of input configured – I’d like to uninstall number and one dash instead the sensor type. For instance: CLOGI C1:1RC C2:-- TEL:+351912345678 Table 4 – Troubleshooting. CLOG500 User Manual...
