Assembly Instructions
1-1-34343
TWO OR MORE ADULTS REQUIRED FOR ASSEMBLY
WARNING:
CHOKING HAZARD -
N ot for children under 3 years.
CONTACT INFO
Hours
Monday to Friday
(9:00am to 5pm EST)
ATTACKER
HOVER HOCKEY TABLE
WARNING:
ADULT ASSEMBLY REQUIRED -
Small parts.
Product must be assembled by an adult.
Technical Support
Email us at:
Visit us at:
Call:
www.eastpointsports.com
PATENT - www.eastpointsports.com
TM
consumerservice@eastpointsports.com
www.eastpointsports.com
973-585-4747
115V AC 60Hz 0.77A Motor
Advertisement
Table of Contents
Related Manuals for EastPoint NHL ATTACKER HOVER HOCKEY TABLE
Summary of Contents for EastPoint NHL ATTACKER HOVER HOCKEY TABLE
- Page 1 PATENT - www.eastpointsports.com ATTACKER HOVER HOCKEY TABLE Assembly Instructions 1-1-34343 TWO OR MORE ADULTS REQUIRED FOR ASSEMBLY WARNING: WARNING: CHOKING HAZARD - ADULT ASSEMBLY REQUIRED - Small parts. N ot for children under 3 years. Product must be assembled by an adult. 115V AC 60Hz 0.77A Motor CONTACT INFO Hours...
-
Page 2: Contact Info
IMPORTANT - Lay out all parts before you begin • Please review the parts identifier and make sure that you have all parts before beginning assembly. • If any questions or issues, please contact us at 1-973-585-4747 BEFORE returning the product to the original place of purchase. - Page 3 BEFORE BUILDING - Please inspect your playfield Your Table Game Playfield is NOT replaceable. Any damage that exists to your playfield is not reparable under warranty. If your playfield is damaged, the entire game must be returned to the original place of purchase for an exchange. Please attach RECEIPT HERE It will be required to receive service help or parts under warranty.
-
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read all instructions – All the safety and operating instructions should be read carefully before this Hover Hockey table can be operated or played. Caution – This is not a toy and is intended for use by or under the supervision of adults. Adults should review safety guidelines with children to avoid possible risk of electric shock or other injuries. - Page 5 TOOLS Required Recommended (Not Required): • Phillips Head Screwdriver • Electric Screwdriver or Power Driver (Standard Size) – Not Included CAUTION: DO NOT OVER TIGHTEN. If using an Electric Screwdriver or Power Driver please make sure that the tool is set to a very low torque to •...
- Page 6 HARDWARE Bolt - Hex Washer Bolt Wrench 34343-60ES 34343-61ES 34343-62ES 34343-63ES STEP 1 STEP 1 STEP 2 Allen Key Screw - Power Corner 34343-64ES 34400-60ES PRE-INSTALLED ACCESSORIES Hockey Pusher Puck Felt Pad 34343-80ES 34343-82ES 34343-81ES PRE-INSTALLED ASSEMBLY INSTRUCTIONS Hockey Table Construction START BEFORE BUILDING - Please inspect and layout all your PARTS Please review the...
- Page 7 NOTE: STEP 1 Legs should COMPONENTS QTY. NOTE: angle out! Install 3 Bolts for Main Cabinet each Leg. Leg - Left Repeat for all 4 Leg - Right Legs. DO NOT overtighten Bolts. HARDWARE QTY. Bolt - Hex Washer Wrench STEP 2 COMPONENTS QTY.
- Page 8 STEP 4 DO NOT COMPONENTS QTY. NOTE: lean table Using at least 2 Step 3 Assembly on legs! STRONG ADULTS, pick up & flip table over. Lift table & turn it in the air. IMPORTANT: To avoid damage, Lift table and turn it DO NOT lean table in the air.
-
Page 9: Electrical Connections
ELECTRICAL CONNECTIONS CONNECTION DIAGRAM COMPONENTS QTY. Led Scoring Battery Box Scorer Base Box Goal Box with Wire - Unscrew and remove cover. - Insert 4 AA Batteries (Batteries not included). - Return cover and insert Screw. PLUG IN THE TABLE COMPONENTS QTY. - Page 10 SCORER OPERATION LED SCORING OPERATION PLAY/RESET TIME SOUND HOME AWAY POWER SCOREBOARD OPERATION POWER Slide the Power Switch over to turn the scoreboard ON/OFF. SELECT PLAYING TIME Press the TIME button to scroll through the playing time options. • 3 Minutes •...
-
Page 11: Schematic Diagram
SCHEMATIC DIAGRAM THERMAL PROTECTOR CONNECTOR SPT-2 POWER CORD MOTOR ON/OFF SWITCH POLARIZED PLUG ELECTRIC RATING: 115V AC - 60Hz 0.77A TABLE MAINTENANCE AND CARE TABLE TOP • If Hover Hockey surface needs to be cleaned, you can use any gentle surface cleaner (not bleach or ammonia) with a lint free cloth. FCC IDENTIFIER : This device complies with part 15 of the FCC rules. - Page 12 Limited Warranty As described in and as limited by this Limited Warranty, EastPoint Sports, Ltd. (the “Company”) warrants this Table Game (the “Product”) to be free from defects in workmanship and materials for a period of 90 days from the date of original purchase. The term defects shall mean any imperfections that impair the use of the product. The Company reserves the right to request confirmation of Proof of Purchase when requesting parts or service in order to confirm that the game is within its warranty period.
Need help?
Do you have a question about the NHL ATTACKER HOVER HOCKEY TABLE and is the answer not in the manual?
Questions and answers
My table won’t power on when plugged in. It worked well for one year but now won’t turn on.
The EastPoint NHL ATTACKER HOVER HOCKEY TABLE may not power on when plugged in due to the following reasons:
1. Power Switch – Ensure the ON/OFF switch is turned on.
2. Polarized Plug – The plug must be inserted correctly into the outlet. If it does not fit, try reversing it. If it still does not fit, the outlet may need to be replaced by an electrician.
3. Electrical Issues – Check if the power outlet is functioning properly by testing it with another device.
4. Motor or Blower Issues – If there is abnormal noise or a change in airflow, the motor may require servicing.
5. Damaged Power Cord – Inspect the power cord for any visible damage or disconnection.
If the table still does not power on, contact EastPoint Sports technical support at 973-585-4747 for further assistance.
This answer is automatically generated
