Don Park B-VENT BVS Installation Instructions

U
N I V E R S A L
Installation Instructions
Engineered to be used in retrofit B-Vent to B-Vent chimney applications only. For use
with all approved type "B" gas vents listed with ULC/UL. Male/Female adaptors are
manufactured for use above or below the roof line.
½" Airspace Application
1. Slide adaptor over existing vent as far as it will go.
2. Locate draw band maximum of 1/2" from raw end of adaptor.
3. Install 2 #8 x 3/8" sheet metal screws (provided) through draw band and both outer
casings to ensure that there is no slippage. (NOTE: be sure not to tighten and puncture
the inner liner.)
4. Then silicone all exposed seams/joints using silicone with a temperature rating of 300
deg. F (150 deg. C) or more.
5. Continue retrofit with Don Park B-vent only.
1
B - V M
E N T O D E L
A
D A P T O R
B-Vent Model BVS Universal Adaptor. Revised Feb 7, 2011. V.1.0 DPBVUA
SHEET METAL & HVAC SUPPLIES
Head Office
2259 Markham Road
Scarborough, Ontario, Canada M1B 2W3
T. (416) 449-7275
www.donpark.com
BV S
( ,
B M U A B F U A
For use with listed Don Park and
Energy Vent type B-vent
F. (416) 449-2614
)
