USER MANUAL
ENGLISH VERSION
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SJ 200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ScubaJet SJ 200

Summary of Contents for ScubaJet SJ 200

  • Page 1 USER MANUAL ENGLISH VERSION...

  • Page 2: Table Of Contents

    7.4. Buying batteries Important safety & operating information 8.1. Danger warning for risk of injury to yourself or others 8.2. Warning about the risk of damage to or by your SCUBAJET 9. Warranty terms 9.1. Warranty process 10. Transportation of the SCUBAJET...

  • Page 3: Introduction

    We want to make sure you stay safe while using your SCUBAJET, so we created this manual with a lot of care. Now it’s up to you, to read it carefully, so you may use your SCUBAJET properly and enjoy it for a long time.

  • Page 4: Starting Up - Scubajet In Use

    SCUBAJET properly. Once the SCUBAJET is set up, go to relevant section with your activity as follows: For the use while snorkeling, swimming and diving go to section 4. For the use on a SUP go to section 5.

  • Page 5: Charging Scubajet

    2.2. CHARGING SCUBAJET Charging the battery Connect the power cord to the power Connect the power supply to the charger. supply. Put the battery into the charger and fasten it Connect the power cord to the mains. with the metal ring.
  • Page 6 Charging the remote control and the repeater for use on SUP Put the remote control and the repeater Connect the power cord to the mains. into the 2 slots on the charger. Batteries are full when lights are green.

  • Page 7: Setting Up The Scubajet With The 400 Wh Battery

    2.3. SETTING UP THE SCUBAJET WITH THE 400 WH BATTERY Inserting the battery and fixing the tube The SCUBAJET 200 will be delivered with the tube already mounted. You may skip this step. When connecting the motor unit with the Slide the battery into the tube (so the end...
  • Page 8 (for early SCUBAJET versions). If there is no nose-tool to be found within the packaging, rotate the cap by hand only.

  • Page 9: Parts Diagram And Technical Specifications

    3. PARTS DIAGRAM AND TECHNICAL SPECIFICATIONS 3.1. SCOPE OF DELIVERY DIVE PACKAGE If you decided to order a dive package, you control the SCUBAJET directly via the 3 speed steps on the function ring. YOU DON‘T NEED A REMOTE CONTROL OR REPEATER. Nozzle Water intake (Grille) E-Motor Nose Opening Tool (only available with earlier versions.

  • Page 10: Scope Of Delivery Sup Package

    3.2. SCOPE OF DELIVERY SUP PACKAGE In order to actuate your SCUBAJET and adjust the speed on a SUP board, you need the remote control. The positions *, ** and *** on the function ring do not apply when using the SCUBAJET SUP Package.

  • Page 11: Technical Specifications

    3.3. TECHNICAL SPECIFICATIONS Name of model SJ 200 Max. propulsive power (in watt) 1000 Battery (in watt hours) per unit Number of battery units Battery modules status for transportation disconnected Battery type Li-Ion Related voltage (in Volt) 22,2 Battery operating / storage temperature -20°C to +60°C (-4°F to +140°F) Battery charging / storage temperature 0°C to +45°C (-32°F to +113°F)
  • Page 12 Battery operating / storage temperature -20°C to +60°C (-4°F to +140°F) Battery charging / storage temperature 0°C to +45°C (-32°F to +113°F) Total weight including battery 3,2 kg Length SCUBAJET 580 mm Diameter SCUBAJET 80 mm) Battery life at top speed (in minutes) 20 min Speed...

  • Page 13: Using Scubajet While Snorkeling, Swimming And Diving

    AND DIVING You are holding the world’s smallest dive scooter in your hands. By using your SCUBAJET with the dive adapter, you are able to swim at a speed that is nearly Olympic level. Your underwater experience while diving or snorkeling will be enhanced as well. You will be ready to...
  • Page 14 Cant the SCUBAJET slightly and fix the screw clockwise. Switch the function ring to one of the 3 Go into the water and hold the SCUBAJET speed levels I, II or III, whereas I is the with the dive adapter. In order to activate slowest and III is the fastest level. There is...
  • Page 15 CAUTION Do not dive deeper than you would usually do when snorkeling, to ensure you can get back to the surface safely! CAUTION Do not stick body parts, clothing or other objects into the water intake (grille) of the SCUBAJET. Loose body parts (e.g. hair etc.) or flowing clothing or equipment could be drawn into the water intake (grille) due to caused suction!

  • Page 16: The Function Ring On The Motor Unit

    The function ring should always be on the The function ring shall be turned to the “off” Position if the SCUBAJET is not in use. relevant position as stated in the following sections, depending on choice of use.

  • Page 17: Using The Scubajet On Your Sup

    SUP board onto the next level. Train your balance and strength on your SUP and go longer distances and at higher speed with your brand new SCUBAJET. Now you are able to enjoy paddling to the fullest. You will be ready to start off within seconds! Read on and find out, how you can mount the adapter to your board and attach the...
  • Page 18 Attach the SUP adapter to the adapter rail on the tube and connect the finbox adapter to the Finbox on your SUP. We recommend connecting SCUBAJET with a thin lanyard somewhere on your SUP. Switch the function ring on the motor unit to Switch the remote control to „ON“...
  • Page 19 Put the SUP with the SCUBAJET in the water and make sure that you have enough space and that you do not hit any obstacles. The SCUBAJET only works if it’s underwater. The repeater is absolutely necessary for proper usage of the SCUBAJET and must be...

  • Page 20: Remote Control

    / the repeater, top left you see the battery type of the SCUBAJET (200 wh / 400 wh). The display in the middle x % shows the output, bar shows the remaining runtime in minutes.
  • Page 21 Modify the motor acceleration characteristic (RAMP) RF Pairing Initiates the pairing process between remote, repeater and SCUBAJET. Please watch our Support-Video, in case you need to pair the SCUBAJET. https://www.youtube.com/watch?v=r_TUXoXcACI Pairing the SCUBAJET with the remote control and the repeater When you get your SCUBAJET, it is already paired with the remote and repeater contained in your packaging.
  • Page 22 2 seconds. 4 If you want to use the devices differently (remote as repeater or vice versa) you need to open the menu, switch to remote / repeater and leave the menu by pressing the left-hand button before re-pairing. Turn the SCUBAJET function ring to speed 3 (***).
  • Page 23 8 The pairing process starts once „REQ received“ appears on the remote. Wait until both devices display „pairing successful“. The repeater flashes blue on the top left, this signals it is operational. Turn the SCUBAJET function ring to wireless before using it.
  • Page 24 10 In the packaging a clip-set is to be found. With these clips, you are able to mount the repeater directly to your SUP board and the remote to your paddle or wrist. Speed may be adjusted by twisting the ring on the remote counter-clockwise: Speedsteps 1, 2 and 3 are not necessary for the use with the remote, but for underweater use only (dive,...

  • Page 25: After Using Scubajet

    6. AFTER USING SCUBAJET Remember, sun and salt water can harm your skin. So they may harm your SCUBAJET as well. Read on and find out, what to consider when your SCUBAJET is not in use.
  • Page 26 Turn the function ring to off. Rinse with fresh water. Try to keep the SCUBAJET in a shadowy Wait until the SCUBAJET is dry. place. Remove the battery (see section „Removing Keep battery in a dry and shadowy place. the battery“).

  • Page 27: Battery Use & Care Information

    7. BATTERY USE & CARE INFORMATION Your SCUBAJET works with a Li-Ion battery, that needs to be handled with care. We want you to enjoy your SCUBAJET products safely and for a long time. Please read this manual carefully and...

  • Page 28: Battery Use

    (cigarettes, sparks). . Only use the charger supplied with your SCUBAJET package . Do not charge the battery in temperatures above 45ºC (113ºF) as significant off gassing may occur. Keep the battery and SCUBAJET in a dry and shadowy spot when not in use. Always connect the charger to the battery first and then plug the charger into the mains. After charging, disconnect from the mains first and then disconnect the battery from the charger. After charging is complete the battery will continue to off gas. You should wait at least 30 minutes after charging before removing the battery from the charger. Failure to do so could result in an...

  • Page 29: Storing Batteries

    To ensure proper storing of battery, read the following: Do not store the battery in temperatures above 45ºC (113ºF) as significant off gassing may occur. Keep the battery and SCUBAJET in a dry and shady spot when not in use. If the battery is not to be used for an extended period of time, store it in a well-ventilated area and away from children, heat and ignition sources and recharge it every two months to maintain charge and avoid excess of gassing.

  • Page 30: Important Safety & Operating Information

    8. IMPORTANT SAFETY & OPERATING INFORMATION 8.1. DANGER WARNING FOR RISK OF INJURY TO YOURSELF OR OTHERS We guarantee that our products meet the highest security and safety standards as long as they are used as suggested in our user manual. To ensure safety, please read this user manual carefully before use, and follow the included instructions.
  • Page 31 Ignoring the instructions in this manual or mishandling the SCUBAJET could cause malfunction, operational problems to the device, damage, or personal injury. SCUBAJET accepts no liability for any damage caused by actions that contradict this operating manual. Children under the age of 16 should not be allowed to operate the SCUBAJET. Note that only healthy and experienced swimmers are allowed to use SCUBAJET.
  • Page 32 Be aware of appropriate water levels, tidal changes, dangerous currents, weather changes and strong offshore winds. Always scout unfamiliar water. Be careful not to hit other items when diving with the SCUBAJET. Make sure to stay away from boats, bridges, rocks or any items which could hurt you.
  • Page 33 Wear proper clothes The SCUBAJET is not a personal floatation device. The SCUBAJET does not have any flotation and will sink in water. When using the SCUBAJET with SUP, canoe, kayak, dinghy or kayacat, always wear a life jacket and never go without a paddle. Only go over distances you can easily paddle back without SCUBAJET support.

  • Page 34: Warning About The Risk Of Damage To Or By Your Scubajet

    Every two months use contact spray to care for all electronic contacts. You will extend the lifespan of your battery, if you do not expose it to hot environments for long periods of time. Always keep the SCUBAJET out of direct sunlight when not in use. Heat kills batteries.

  • Page 35: Warranty Terms

    Any claims by the final purchaser for any expense for the repair of a material or manufacturing fault will be settled by SCUBAJET. Claims may not include or do not cover incidental costs of a warranty claim or any other financial losses (e.g. costs for towing, telecommunications, food, accommodation, loss of earnings, loss of time etc.).

  • Page 36: Warranty Process

    SCUBAJET decides whether faulty parts are repaired or replaced. Distributors and dealers who repair a SCUBAJET have no authority to make legally binding statements on behalf of SCUBAJET SCUBAJET is entitled to refuse a warranty claim in case...
  • Page 37 Customers are responsible to adhere to all regulations of international transport by air (IATA) and road - especially for shipping Lithium Ion Batteries - and any customs/duty regulations. SCUBAJET is not responsible for any violations of these regulations by any customer shipping internationally.

  • Page 38: Transportation Of The Scubajet

    Li-Ion batteries are subject to specific rules by the airline authorities. The transportation of the 2x100 wh battery (in a disconnected status) should be possible according to IATA rules. SCUBAJET however does not take any responsibility in the matter. Please contact your operating airline.

  • Page 39: Preparing The Battery For Transportation Via Airplane

    10.1. PREPARING THE BATTERY FOR TRANSPORTATION VIA AIRPLANE Disconnecting the battery units This section refers to the 2x 100 wh battery type, which may be taken on airplanes in your carry on luggage. Therefor you need to take the following steps. In case you own the 400 wh battery, you may skip this step, for the units are not able to be disconnected.
