RECEIVING, HANDLING AND STORAGE

RECEIVING
These relays, when not shipped as a part of a
control panel, will be shipped in cartons designed
to protect them against damage. Immediately upon
receipt of the relay, an examination should be made
for any damage sustained during shipment.
jury or rough handling is evident, a damage claim
should be filed at once with the transportation
company and the nearest General Electric Sales
Office should be notified promptly.
LOCATION
The location should be clean and dry, free from
dust and excessive vibration, and well lighted to
facilitate inspection and testing.
MOUNTING
The relay should be mounted on a vertical sur­
face. The outline and panel drilling dimensions are
shown in Fig. 20 for relay Types IAV51A, IAV51D,
IAV52A, and IAV53C.
panel drilling for relay Types IAV51K,
lA lA
V53B and V53D.

TARGET AND SEAL-IN UNIT

For trip coils operating on currents ranging
from 0.2 up to 2.0 amperes at the minimum control
voltage, set the target and seal-in tap plug in the
0.2-ampere tap.
For trip coils operating on currents ranging
from 2 to 30 amperes at the minimum control volt­
age, place the tap plug in the 2.0-ampere tap.
The tap plug is the screw holding the right­
hand stationary contact of the seal-in element. To
change the tap setting, first remove the connecting
plug. Then, take a screw from the left-hand sta­
tionary contact and place it in the desired tap.
Next, remove the screw from the other tap, and
place it in the left-hand contact.
necessary to prevent the right-hand stationary con­
tact from getting out of adjustment. Screws should
be
not in both taps at the same time as pickup for
d-e will be the higher tap value and a-c pickup will
be increased.
VOLTAGE
The voltage at which the contacts operate may
be changed by changing the position of the tap plug
in the tap block at the top of relay for relays such as
If

INSTALLATION

Fig. 21 shows outline and
lA
V53A,
ADJUSTMENTS
This procedure is
SETTIN G
Voltage Relays Type IAV
Reasonable care should be exercised in un­
packing the relay in order that none of the parts get
injured or the adjustments disturbed.
in­
If
the relays are not to
they should be stored in their original carton in a
place that is free from moisture, dust, and metallic
chips.
CONNECTIONS
Internal connections are shown in Figs. 9 to 15
for the various relays.
G ROUND CONNECTIONS
One of the mounting studs or screws should be
permanently grounded
&
than No. 12 B S gage copper wire or its equiva­
lent.
the IAV51A, IAV52A, IAV53A, IAV53B, and IAV53D
which have tapped coils.
ment is from 55 to 140 volts on the 115 volt ratings
and 110 to 280 volts on the 230 volt ratings. The
Type IAV51D is provided with a four-tap resistor
in series with an untapped coil.
vided with taps, screw the tap plu g firmly into the
tap marked for the desired voltage (below which the
relay is not to operate).
The pickup of the relay for any voltage tap is
adjusted by means of a spring adjusting ring. The
ring may be turned by inserting a tool in the notches
around the edge (see Fig. 16).
ring, the operating voltage of the relay may be
brought into agreement with the tap setting em­
ployed if, for some reason, this adjustment has
been disturbed.
desired setting between the various taps. The relay
is adjusted at the factory to operate from any time­
dial position at a minimum voltage within five per­
cent of the tap setting for the relays with tapped
coil mentioned above.
tapped coils, pickup occurs at a voltage which is
8 percent of rated voltage.
80 percent of the operating value on all of the over­
voltage relays.
voltage relays is the minimum voltage for a given
tap setting at which the contacts just make.
HANDLING
STORAGE
be
installed immediately,
by a conductor
The range of this adjust­
For relays pro­
By turning the
The adjustment also permits any
For those relays with un­
The relays reset at
Operating voltage for the over­
GEH-1814
not less
