Commissioning Task List – Sidewall Sensing
Task
Install / wire FHM/C controller box
1
Install / wire FHM/C LCD screen
2
Install sidewall sensor and wire to FHM/C
3
controller
Wire exhaust valve's actuator and
4
transducer to FHM/C controller
Confirm correct wiring via FHM/C's I/O
5
Diagnostic Screen (i.e. stroke valve and
confirm air flow from AI1 - [valve] and AI2
[sidewall sensor])
Turn on / operate hood exhaust at lower
6
end of anticipated static pressure
FHM/C's Exhaust Setup Screen - enter
7
correct values
FHM/C's Set Point / Control Screen -
8
enter correct values
Adjust K Factor on FHM/C's Exhaust
9
Setup Screen
(if needed
Adjust FPM readout from commissioning
10
screen (if needed
Set correct valve position for needed
11
airflow at sash stop position
FHM/C's Alarm Setup Screen - enter
12
correct values
FHM/C's Network Setup Screen - enter
13
correct values (optional)
FHM/C's General Setup Screen - enter
14
correct values (optional)
Fume Hood Monitor and Controller – User Guide
by balancer)
by balancer)
Dependent /
preceding
tasks Typical task owner
Electrician
Electrician
1
Electrician
1
Electrician
1
Electrician
1-4
Commissioning agent
/ air balancer
Commissioning agent
/ air balancer
Commissioning agent
/ air balancer
Commissioning agent
4, 6
/ air balancer
Commissioning agent
3, 8
/ air balancer
Commissioning agent
8, 9
/ air balancer
Commissioning agent
/ air balancer
Commissioning agent
/ air balancer
Commissioning agent
/ air balancer
