Plastic Safety Systems, Inc. SafetyRail Assembly Instructions

Attach Guide Rails to the First Upright:
LIST
Use the
Line-up - Insert - Secure - Turn
1
Before you begin:
• Always assemble SafetyRail on-site.
Do not attempt to drag an assembled
array to another location.
• For a successful assembly:
Always attach the lower guide rail first!
4
Secure
the upper and lower notches
of the guide rail with the bushing.
Use the side of the bushing that is
closer to the direction in which the
barricade array will be built.
SafetyRail
ADA-Compliant Pedestrian Barricade
Assembly Instructions
No hand tools required.
method
2
Line-up
upright.
5
Turn
the guide rail into a position perpendicular to
the upright.
The guide rail should turn easily, without force.
If the guide rail binds, do not force it to turn.
Simply, reverse the process: disengage the guide
rail, and start again.
™
3
the guide rail with the
Insert
the guide rail into the
of the bushing.
The inserted end of the guide rail
must rest flush against the back of
the upright.
6
At this point, the SafetyRail
Barricade should look just like this.
For instructions to attach the
second upright, see over.
center
