Summary of Contents for Vision S-8070-A
- Page 1 8' x 7' Vinyl Storage Shed Model #S-8070-A Storage Shed Owner’s Manual PLEASE READ OWNER’S MANUAL COMPLETELY 8' x 7' (2.44m x 2.14m) BEFORE ASSEMBLING YOUR BUILDING. ALL STATED SIZES ARE NOMINAL DIMENSIONS.
-
Page 2: Parts List
Parts List PRODUCT LENGTH Congratulations on your purchase of this Vision Vinyl PRODUCT DESCRIPTION (INCHES) Storage Building! As with any construction or assembly project, please exercise caution when using tools and Wall Panel 71.5 equipment to install this structure. Be sure to read and Roof Panel 50.125... -
Page 3: Parts Location
Parts Location RGA-2 Ridge Cap See parts list on F512H02 previous page for Gable End Cap parts description RGB-2 RGB-2 Gable End Cap RGA-2 Outside Vents WP4 WP3 WP23 WP22 WP25 WP24 F512G02 Inside Vents WP10 F512K02 F512K03 F512K05 F512K06 F512G02 F512K04 Door Header... -
Page 4: Parts Identification
Parts Identification Corner Post Wall Panel Roof Fascia Cap Fascia Gable Lintel Ridge Cap (Upside Down) Ridge Beam Roof Panel Base Track Slope Wall Cap Gable End Cap Vent (Inside & Outside) #8 x 1" Pan Head Screws (150) Hinge Screws (12) #8 x 3/4"... - Page 5 Concrete Floor Option Concrete Floor Option You may decide to construct your Vision storage shed on a concrete foundation, in which case it is recommended that you engage the services of a concrete contractor. Prior to having a concrete foundation poured...
- Page 6 Wood Floor Option Wood Floor Option If you choose to construct your Vision storage shed on a wood foundation, follow these recommendations to achieve the best results. Use only treated lumber, as standard 2 x 4’s and plywood will deteriorate rapidly, compromising your building in a relatively short time.
- Page 7 Assembly Position 11 Base Tracks on platform as shown (rear tracks are longest). Allow 72-1/2" between front Base Tracks for door placement. Tip: Use the door lentil (F512101) as a measurement guide to confirm the door opening length and position for placement of the base tracks.
- Page 8 Panel Assembly – General Instructions Vision Shed Wall Panels, Roof Panels and Corner Posts make assembling your building easy. Each panel and post is engineered the same way: Integrated Vinyl Channel Locks are integrally molded the full length of the panels and are simply “snapped together,” locking the pieces securely to create incredibly sturdy walls and roof.
- Page 9 Panel Assembly – Left Front Wall Locate the preassembled, left front wall section. To differentiate the left section from the right, hold both sections upright on the shed base. The left front wall (as seen from outside the shed) has the aluminum door frame preinstalled on the right side of the section.
- Page 10 Panel Assembly – Remaining Walls Back wall Locate and arrange the back wall panels from shortest to the highest (peak) to create two separate half wall sections. Again, making sure the DEEP Channel locks face out, join the panels together as with previous assembly instructions.
- Page 11 Ridge Beam With an assistant holding one end of the ridge beam, position the front of the beam at the flat edge of the header peak and the back wall peak. It also may be necessary to stand on a ladder for this assembly step.
- Page 12 Ridge Cap With both you and your assistant standing on ladders at each end of the roof, position the ridge cap over the ridge beam making sure each end is flush with the outer edge of the outermost roof panel. With the rubber mallet, strike the top of the ridge cap nearest the edge of the roof so that its tabs seat on the vertical member of the ridge beam.
- Page 13 Doors Locate the left and right hand doors. The right hand door features a full length astragal door strike along one edge (Diagram 15A) which closes over the left hand door. Doors must be installed so that they open out from the shed. Install the right hand door first by aligning the top and bottom hinges with the predrilled holes in the aluminum frame of the door...
- Page 14 Wall Vents Locate the inner and outer vent covers for the two back wall vents. The inner vent cover has a screw hole near the top and bottom of the vent. The outer vent cover has no screw holes. Position the outer vent covers into the vent openings. Position the inner vent covers into the openings from inside the shed.
- Page 15 Affixing Hooks and Shelf Brackets Hooks, shelving and other storage devices can be installed on the walls of your Vision Vinyl Shed just as simply as in your garage. Screws or other threaded fasteners to affix hooks, hangers and shelving, should be inserted ONLY in the scored (indented) groove located 3/8"...
