Comeup 882756 Manual

I.Specifications
1. Transmission range: 15 ~ 27 m (50 ~ 90 ft)
2. Receiver operation voltage: 8 - 24 V
3. Protection: IP 66
4. Operating temperature range: -20°C ~ +65°C
III Operation
1. Install and replace battery.
a. Remove the three screws from the wireless transmitter.
b. Separate the top section and remove the old battery and dispose it.
c. Insert new battery and join the top section with the bottom section.
d. Make sure to fasten the three screws.
2. Start
a. Attach the red(+) and black(-) battery leads to battery set on the vehicle. Press the
Cutout switch , then the buzzer alarms for decoding and all LED flash.
b. Hold the Power Button of the transmitter for about 5 seconds，then the LED Indicator
lights permanently.
c. Hold either Cable In Button or Cable Out Button of the transmitter, then the buzzer
alarms long sound lasting for 5 seconds.
d. Only flashing LED on Logo and Vehicle Battery Life..
e. The wireless remote control is now workable.
Power Button
Cable IN
1. Cutout Switch
Your Seal Gen2 9.5i/9.5si /9.5rsi Winches have a cutout switch to
activate or deactivate the winch.
The cutout switch on the Seal Gen2 9.5rsi models also deactivate the
wireless receiver to prevent parasitic draw.
2. Vehicle Battery Life
Your Seal Gen2 9.5i/9.5si/9.5rsi Winches indicate the status of vehicle battery level.
The fan-shaped out Vehicle Battery Level indicate the status of your vehicle battery level by
locating block and changing color。 If your battery level at an extreme low level, your must
charge the battery immediately. The minimum requirement for a 12 V vehicle battery is 650
cold cranking amps。
st
1 Icon (Green): Fully charged
nd
2 Icon (Green): Fair charged
rd
3 Icon (Green): Fair charged
th
4 Icon (Green): Low charged
th
5 Icon (Red): extreme low
Wireless Remote Module
Wireless Receiver Model NO：882756
LED Indicator
Cable OUT
Lithium Battery: CR2032 (3V)
1
IDB
about 12V level
about 11V
about 10 V
about 9V
below 8V
