USBTTX CONFIG USER GUIDE
ATEX APPROVED MODULE FOR TTR200X, TTC200X,
SEM1801XR, SEM1802XR, SEM1801XTC, SEM1802XTC
FOR USE IN SAFE AREA ONLY.
Important - Please read this document before any installing.
Every effort has been taken to ensure the accuracy of this document, however we do not accept responsibility for damage, injury, loss or
expense resulting from errors and omissions, and we reserve the right of amendment without notice.
IMPORTANT - CE & SAFETY REQUIREMENTS
Product must be used inside a suitable safe area.
The product contains no serviceable parts, or internal adjustments. No attempt must be made to repair this product. Faulty units must be
returned to supplier for repair.
This product must be used by a qualified person.
ABSOLUTE MAXIMUM CONDITIONS ( To exceed may cause damage to the unit) :-
Ambient Temperature (0 to 40) °C Humidity (10 to 95) % RH (Non condensing)

1.0 DESCRIPTION

1.1 The USBTTX ATEX approved module in conjunction with the USB-CONFIG-MKII configuration unit provides a USB powered
interface between a Windows computer and Status Instruments TTR200X, TTC200X, SEM1801XR, SEM1802XR, SEM1801XTC,
SEM1802XTC configurable temperature and process instruments.
1.2 Using a standard PC USB port the module enables the user to interrogate their equipment. The transmitter or any connections to it
must be located in the safe area. Including re-ranging and re-configuration using a Windows based interface.

2.0 RECEIVING AND UNPACKING

2.1 Please inspect the packaging and instrument thoroughly for any signs of transit damage. If the instrument has been damaged,
please notify your supplier immediately

3.0 PRECAUTIONS

3.1 Do not allow the two terminal/crocodile clip connections on the output of the USB-CONFIG-MKII to short together, the module
provides 24V DC across these terminals in order to power the unit under configuration. Whilst the USB Config is protected by a self-
resetting circuit, certain models of PC are not protected against high current draw from their USB ports and damage could be caused
if the user is not careful.
3.2 Do not attempt to configure anything but approved configurable equipment; doing so could damage the USB Configuration
equipment as well as the host computer.
3.3 Connecting the USB configuration module to powered equipment incorrectly can permanently damage the USB configuration
equipment or the TTR200X, TTC200X, SEM1801XR, SEM1802XR, SEM1801XTC or SEM1802XTC.
3.4 Do not use the USB Configuration equipment as a power supply, and ensure that it is not (accidentally or intentionally) used to
power a process loop or any other instrument.
Configuration – Only to be performed in the safe area
EX
The TTR200X, TTC200X, SEM1801XR, SEM1802XR, SEM1801XTC, and SEM1802XTC can only be configured whilst connected to the
USBTTX and USB-CONFIG-MKII, powered by a Windows computer . This may only be performed in the safe area.
Note:- The instructions contained in this document superceed any information or documentation supplied with the USB-CONFIG-
MKII module when it is used with the USBTTX.
