INSTALLATION INSTRUCTIONS
Saw (Reciprocating or Jigsaw)
Electric Drill
(Drill Bit large enough to create
a "start" hole for the saw)
Caulk or Silicone Sealant
Phillips Head Screw driver
Standard head screw driver (for Security Screws)
The package you received should contain:
Security Boss MaxSeal Pet Door®
(Wall Mount models include an attached tunnel)
Insulated Security Panel with Replacement Rivets
1/2" #6 Security Screws for tamper proof installations
Indoor Outdoor Carpet (Wall Mount models only)
Foam Tape (Storm Door model only)
(Will vary depending on your particular type of installation)
Pencil
Level
(Inner frame and outer frame)
1/2" #6 Phillips Head Screws
7/64" Drill Bit
Allen Wrench
Tools you may need:
Circular saw with wood or masonry blade
5/16" masonry bit (if installing in concrete)
Congratulations on your purchase of a
MaxSeal Door by Security Boss®.
The following is a step by step guide for
installing your Security Boss® product.
A SAFETY REMINDER!
Always wear eye protection and gloves
when appropriate.
Drywall saw
Utility knife
Scissors or snips
Masking tape
Tin snips
Stud finder
Tape measure
Advertisement
Table of Contents
Related Manuals for Security Boss MaxSeal
Summary of Contents for Security Boss MaxSeal
- Page 1 Congratulations on your purchase of a MaxSeal Door by Security Boss®. The following is a step by step guide for installing your Security Boss® product. A SAFETY REMINDER! Always wear eye protection and gloves when appropriate. INSTALLATION INSTRUCTIONS The package you received should contain: Security Boss MaxSeal Pet Door®...
- Page 2 When installing a Door model, try to position the location of the rough opening such that it is no closer to the edge of the door than 3" to maintain structural strength within the door. The MaxSeal frame fits doors 1-1/4" to 2" thick. (Storm Door models have a range between 7/8" and 1-1/4".) For Wall models check both sides of the wall to make sure the area you cut is free of wiring, plumbing, or any other obstructions.
- Page 3 Step 7: Put the inner frame (the one with the insulated security panel) into the rough opening in the people door. Snap the outside frame into MaxSeal door and sleeve the pet door frame together. Step 8: Using the pre-drilled pilot holes and supplied drill bit, drill and insert one screw.
- Page 4 Insert supplied screws into the drilled holes. The number of side screws varies with the size of pet door. (Security Boss Manufacturing has included One-Way Security Screws as well as Philips head screws to give customers a Tamper-proof option in their door...
- Page 5 Step 2: Check the package you received to make sure that it contains all the necessary parts. Step 3: Select the pane of glass in the French door you plan to mount your MaxSeal® pet door. Make sure there is adequate room for removal of the Insulated security panel that lifts out vertically (side loaded panel models are available).
- Page 6 Retighten the thumbscrews using the included Allen wrench. The magnets on all MaxSeal doors are adjustable. This allows a precise seal no matter the weather or size of the flap throughout the years. The magnets are positioned in the frame with a pressure fit. The Magnet is held by an aluminum carrier that can slide in and out of the painted frame rail.
