Crystal Quest
INSTALLATION AND OPERATION GUIDE
CQE-UV-00101
CQE-UV-00102
CQE-UV-00103
CQE-UV-00104
CQE-UV-00105
ONLINE WARRANTY INFORMATION
CrystalQuest.com/warranty.html
Copyright 2018
Crystal Quest
®
All rights reserved
MADE IN THE USA
UltraViolet Disinfection System
®
MODELS:
1 GPM
6 GPM
8 GPM
12 GPM
24 GPM
CQE-UV-00106
36 GPM
CQE-UV-00107
48 GPM
CQE-UV-00108
60 GPM
CQE-UV-00109
72 GPM
CQE-UV-00110
84 GPM
COMPONENT S
1
Advertisement
Table of Contents
Related Manuals for Crystal Quest CQE-UV-00101
Summary of Contents for Crystal Quest CQE-UV-00101
- Page 1 Crystal Quest UltraViolet Disinfection System ® INSTALLATION AND OPERATION GUIDE MODELS: CQE-UV-00101 1 GPM CQE-UV-00106 36 GPM CQE-UV-00102 6 GPM CQE-UV-00107 48 GPM CQE-UV-00103 8 GPM CQE-UV-00108 60 GPM CQE-UV-00104 12 GPM CQE-UV-00109 72 GPM CQE-UV-00105 24 GPM CQE-UV-00110 84 GPM ONLINE WARRANTY INFORMATION CrystalQuest.com/warranty.html...
-
Page 2: Important Information
• All water treatment installations must conform to local plumbing, electrical and sanitation codes. These codes are established for your protection. Check with your local public works department for current plumbing codes. • Do not use non-Crystal Quest replacement cartridges. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS – To guard against injury, basic safety precautions should be observed, including the following: WARNING • Read all instructions, specifications, cautions, and warnings before installing and using your UV Disinfection System. Learn the specific details regarding installation and use. Failure to follow them could cause serious property damage. –... -
Page 4: Diagram Of Uv Lamp
DIAGRAM OF UV LAMP (CQE-PT-03269) (CQE-PT-03150) 1 – Gland Nut 6 – Quartz Sleeve (CQE-PT-03270) (CQE-PT-03101) 2 – Inlet 7 – Bulb 3 – Outlet 4 – Stainless Steel (CQE-PT-03267) Reactor Chamber 8 – Ground Wire (CQE-PT-03268) (CQE-PT-03089) 5 – O-Rings 9 –... - Page 5 INSTALLATION/LOCATION 1. Carefully remove the UV lamp from the shipping tube, being careful not to touch the “glass” portion with your fingers. The UV Disinfection System should be mounted in the horizontal position with the inlet/outlet ports facing up. If the system must be installed in the vertical position, make sure the inlet port is at the bottom of the system.
-
Page 6: Uv Installation (Whole House)
OPTIONAL SHUT OFF house-water-filters.htm. VALVE PRE-FILTER POST-FILTER HOT WATER Pipe, shut-off valves, and fittings are not provided by Crystal Quest®. WATER METER TANNIN SOFTENER WATER HEATER BRINE TANK WATER SUPPLY UV INSTALLATION (OTHER) Point-of-Use Bottleless Water Cooler with 1 GPM Ultraviolet... -
Page 7: Operation And Maintenance
OPERATION AND MAINTENANCE NOTE – PRIOR TO PERFORMING ANY WORK ON THE DISINFECTION SYSTEM, ALWAYS DISCONNECT THE POWER SUPPLY FIRST. 1. Regularly inspect your disinfection system to ensure that the UV lamp is operating. 2. Replace the UV lamp with a new lamp after one year of continuous use to insure a high bacteria and virus kill rate. –... -
Page 8: One-Year Limited Warranty
This warranty gives you specific legal rights and you may have other legal rights which vary from state to state. CRYSTAL QUEST® assumes no responsibility for incidental or consequential damages, for damages arising out of misuse of the product, or the use of any unauthorized attachment.
