CHILDREN'S HOME PLAYGROUND SET
series name:
SPIDER-WALL
DSK -3-8.00 (01)
DSK -3-9.00 (01)
Operating Manual
DSK -3-8.00 (01)PS
DSK -3-9.00 (01) PS
MANUFACTURER: ZAO "Zavod igrovogo sportivnogo oborudovaniya"
Montazhnyi proezd, 6, Cheboksary, Chuvashskaya Republic, Russian Federation 428037
IMPORTER: "KIDS AND FITNESS INC.", 140 RIDGEWOOD AVE. SUIT 415, PARAMUS, NEW JERSEY 07652,
+1(201)477.05.02,
INFO@FITNESS-KIDS.COM
Advertisement
Summary of Contents for Kids and Fitness SPIDER-WALL Series
- Page 1 Operating Manual DSK -3-8.00 (01)PS DSK -3-9.00 (01) PS MANUFACTURER: ZAO “Zavod igrovogo sportivnogo oborudovaniya” Montazhnyi proezd, 6, Cheboksary, Chuvashskaya Republic, Russian Federation 428037 IMPORTER: “KIDS AND FITNESS INC.”, 140 RIDGEWOOD AVE. SUIT 415, PARAMUS, NEW JERSEY 07652, +1(201)477.05.02, INFO@FITNESS-KIDS.COM...
-
Page 2: Table Of Contents
PLAYGROUND SET. They should not be discarded as they all contain important information. You will need to refer to these items if you contact “Kids and Fitness Inc.” about your PLAYGROUND SET. Should you transfer your “Kids and Fitness Inc.” products to another person, please be sure the new owner receives all these documents. - Page 3 SAFETY INSTRUCTIONS Please thoroughly read this Operating Manual (hereinafter referred as “OM”) to become familiar with the assembly, order, safe use, maintenance, transportation and storage of the PLAYGROUND SET. Observing the following statements and warnings reduces the likelihood of serious or fatal injury. Assembling, disassembling and installation of the PLAYGROUND SET must be done by not less than 2 adults after careful studying the OM.
- Page 4 3.1.2 The main configuration elements on the PLAYGROUND SET are vertical stanchions connected by the rings. 3.1.3 To diversify play exercises and games the following additional rig and add-in equipment provided by “Kids and Fitness Inc." may be installed on the PLAYGROUND SET - Trapeze DSK -ВО...
- Page 5 DSK 01-003-02+ №2 – 2 pcs. Inset +DSK 05.059 №3 – 1 pcs. DSK 01-035-01 Bushing DSK 05-019 Bushing DSK 05.055 DSK 00-102-01 Upper foot DSK 05-020 Bushing DSK -3-9.00.01 Left arc DSK -3-9.00.01-01 Right arc DSK -3-9.00.001 Circle DSK -3-9.00.002 Ring DSK -3-9.00.02 1.DSK 42х25-001...
- Page 6 GENERAL VIEW OF THE PLAYGROUND SET picture 1. BASE CONFIGURATION UNITS AND DETAILS OF PLAYGROUND SET NOT SPECIFIED ON THE PICTURE 1: Table 3 Inset DSK 01-003-02+ Bushing DSK 05-021 Cap, DSK 00-102-01 +DSK 05.059 item 9, 10, 14, 23 Table 2 Item 11, table 2 item 8, Table 2 Clamp...
- Page 7 Case DSK 05-011 Closing plug DSK 05-012 Сlosing plug D10 item 30, Table 2 item 31, Table 2 item 33 Table 2 Bolt Screw Upper foot DSK 02-006 items 41, 42 Table 2 item 46 Table 2 item 47, Table 2 Washer Allen key item 50, 51, Table 2...
- Page 8 Serious or fatal injury could result. If you have any questions about the assembly of your purchase, contact "Kids and Fitness Inc." at +1(201)477.05.02 Preparation to the installation, tools and equipment. Read these instructions in their entirety before you begin. This will help ensure an easy and safe installation.
- Page 9 6.3.2. Assemble stanchions with rings, arcs, circle and set in vertical position. (Picture 3). Assembling the construction must be done in horizontal position. First fix the circle, arcs and rings onto the lower stanchions. The rest ring put on the stanchions without fixing. Insets should be pulled down the minimal height and tem- porarily fixed by the bolt (item 41, table 2).
- Page 10 6.3.3 Set foots (item 24, table 2) on the stanchions (Picture 4). With the help of plumb line check whether the ladder stanchions positioned vertically relative to the floor. Strut off the stanchions by unscrewing bolts (item 42, table 2), then lock by the nuts (item 51, table 2). For reliable clamp- ing of the PLAYGROUND SET it's necessary to do 1-3 revolution of the bolt after all three upper foots touched the ceiling.
- Page 11 Picture 5. 6.3.5 To assemble trapeze, rope ladder and rope (Picture 6) and insert disk (item 62*, table 2 (Picture 1)). 6.3.6 Set closing plugs (item 33, table 2) on the open holes of the insets (item 8, table 2). It’s acceptable to fix tra- peze and rope ladder on the conjoined jibs.
-
Page 12: Maintenance Instruction
MAINTANANCE INSTRUCTION Check and control of metal constructions of the PLAYGROUND SET 7.1.1 Before using the PLAYGROUND SET it’s always necessary to check: • Integrity of the construction, presence of all elements of the PLAYGROUND SET; • Presence of protective plastic plugs and cups on the holders and fasteners where it’s provided by the OM; •... -
Page 13: Utilization
UTILIZATION 10.1 Before sending the PLAYGROUND SET to utilization it’s necessary to: • Disassemble the PLAYGROUND SET in the order inverted to the assembly order; • Sort details on the type of materials they manufactured of. 10.2 There are no dangerous or hazardous for health and life substances in the components of PLAYGROUND SET. 10.3 Utilization should be conducted in accordance with appropriate rule and regulations of your region/state.
