Summary of Contents for Monoprice 16116

  • Page 2: Table Of Contents

    CONTENTS SAFETY WARNINGS AND GUIDELINES ............................3 CUSTOMER SERVICE ....................................3 PACKAGE CONTENTS ....................................4 ASSEMBLY AND INSTALLATION ............................... 5 TECHNICAL SUPPORT ....................................14 SPECIFICATIONS ......................................14...
  • Page 3: Safety Warnings And Guidelines

    If you have any problem with your order, please give us an opportunity to make it right. You can contact a Monoprice Customer Service representative through the Live Chat link on our website www.monoprice.com during normal business hours (Mon-Fri: 5am-7pm PT, Sat-Sun: 9am-...
  • Page 4: Package Contents

    PACKAGE CONTENTS Please take an inventory of the package contents to ensure you have all the items listed below. If anything is missing or damaged, please contact Monoprice Customer Service for a replacement.
  • Page 5: Assembly And Installation

    ASSEMBLY AND INSTALLATION 1. For ten of the twelve 4040 Corner pieces, attach two T-Nuts using two M8x20 Combination Screws. Tighten the screws slightly by hand, leaving a 3mm gap between the Corner and the T-Nut, as shown in the accompanying drawing.
  • Page 6 2. For the remaining two 4040 Corner pieces, attach one T-Nut using an M8x20 Combination Screw, then attach a second T-Nut using one M8x35 Combination Screw. Tighten the M8x35 Combination Screw until the end of the screw is flush with the back of the T-Nut. This will result in a larger than 3mm gap, but will be necessary when attaching the lower Beam to the two Base Bars.
  • Page 7 properly positioning and securing the Lower Beam Assembly onto the Base Bar. Next, tighten the M8x20 Combination Screw on the other side of the Lower Beam Assembly using the M6 Hexagonal Wrench. Using the same procedure, attach the other Base Bar to the other end of the Lower Beam Assembly. Ensure that the caster holes on the Base Bars are all on the same side.
  • Page 8 7. Using the same procedure as in step 1 above, attach four T-Nuts to each 8080 Corner piece using four M8x20 Combination Screws. 8. Create two Upright Assemblies by attaching two 8080 Corner Assemblies to one end of each Upright piece using the same procedure as in step 3 above. Ensure the exposed sides of the 8080 Corner Assemblies are flush with the end of the Upright, then tighten the M8x20 Combination Screws using the M6 Hexagonal Wrench.
  • Page 9 10. Align the T-Nuts on one of the Upper Beam Assemblies, then slide the Beam Assembly into the grooves on the insides of the two Upright Assemblies, as shown. Position the bottom of the Upper Beam Assembly about 670mm (26.4") above the top of the Base Assembly, then tighten the M8x20 Combinations Screws using the M6 Hexagonal Wrench.
  • Page 10 13. Using two people, lift one of the Wall Plates and place it on the threaded rods on the front of the Wall Plate Adapter Assemblies. For each threaded rod, install one ø8.2xø16x1.5 Washer 1 and one M8 Nut. After all washers and nuts have been installed onto the threaded rods, use the included Level to ensure the Wall Plate is level, then tighten the M8 Nuts using an appropriate wrench (not included).
  • Page 11 18. Using two people, slightly loosen the screws on the upper Wall Plate Adapter Assemblies and adjust the distance between the top of each Wall Plate to match the height of your displays, then tighten the screws to secure the Wall Plate Assembly in place.
  • Page 12 21. Repeat step 20 to install the Mounting Brackets on the other three displays. 22. Using two people, lift one of the displays and hook the Mount Brackets onto the lower Wall Plate on the right side. Slide the display left or right until the left side is at the center of the Wall Plate.
  • Page 13 23. Ensure that all displays are properly positioned, then move around to the back and tighten the screws at the bottom of each bracket to secure the bracket to the Wall Plate. 24. Each Monitor Bracket has two knobs for fine tuning the positioning in or out and up or down.
  • Page 14: Technical Support

    TECHNICAL SUPPORT Monoprice is pleased to provide free, live, online technical support to assist you with any questions you may have about installation, setup, troubleshooting, or product recommendations. If you ever need assistance with your new product, please come online to talk to one of our friendly and knowledgeable Tech Support Associates.
