Summary of Contents for Inter-Tech M-908
- Page 1 M-908 Manual...
- Page 2 Thank you for buying a case from Inter-Tech. You got a high-quality case with a lot of individual controllable light effects and plenty space for large graphics adapter and hard disks. This case is made only for computer assembling and indoor use.
-
Page 3: Specification
Specification Black Color 210(w)x527(h)x512(d)mm Dimension Steel/ABS Material E-ATX/ATX/Micro-ATX/ITX M/B Type 5.25" device 3.5”HDD*3/2.5”SSD*3 7 Slots, supports VGA cards up to 420mm Slots Front Back side 170mm max. height CPU cooler Top: 120mm*3/140mm*2 (optional) Opt. fans Front: 120mm*2 (optional) Rear: 120mm*1 (optional) Buttom*1;... - Page 4 Components Front panel Right side panel Left side panel Dust filter, top Fan, optional Power supply,opt. Mainboard, optional DVD, optional HDD, optional SSD, optional Dust filter, buttom RGB+PWM Stands control...
-
Page 5: Front Connectors
Front connectors USB3.0 M/B I/O connector Fan cintrol Fan control Reset Switch M/B connector Power LED M/B connector HDD LED M/B connector Power Switch M/B connector LED connector H/D Audio USB2.0 M/B connector M/B connector... -
Page 6: Power Supply Mounting
Power supply mounting Cleaning dust filter Insert Power supply Fix it with screws Remove it to the back HDD mounting Mainboard mounting 3,5" clip 2,5" fix with screws Remove tray Fix 3,5" with screws on the buttom... - Page 7 2,5" Hard disk mounting SSD possibility 1+2 Loosen the screw and remove tray Fix SSD with screws onto the tray Place tray SSD possibility 3+4 Hold SSD Fix it with screws from outside Fix it again...
- Page 8 Cable plugs HDD LED M/B connector POWER LED M/B connector Reset S/W M/B connector Power S/W M/B connector 4pin Molex connector for 3pin Fan-plug for manual fan control manual fan control...
- Page 9 Mounting water cooling Possibility 1: Possibility 2: Fix the radiator at the rear fan position Place the radiator behind the front panel and fix it with screws. Dimension water cooling: Front : 240/360mm Top: 280/360mm Back side: 120mm Possibility 3: Place the radiator at the top and fix it with scews buttom-up.
- Page 10 Graphics card holder Mount the graphics card. Adjust the holder according to the build-in graphics card. 1. Height: Loose screw 1, adjust bracket A and fix it. 2. Depth: Loose screws 2+5, adjust bracket C and fix it. 3. Side: Loose screws 3+4, adjust bracket B and fix it.
- Page 11 Connection of fan and RGB lightning You have different possibilities to connect and control fans: 1. Adjustable switch at the top of the case You can connect up to 3 fans with 3pin connector to each slider at the top of the case. You can control the fan speed in three steps, Off, 50%, 100%.
-
Page 12: Connection To The Controller
Check if the switch is connected to plug 8 of the controller. Neither fan nor light works. Check if plug 7 of the controller is connected to the power supply and the power supply is on. Inter-Tech Elektronik Handels GmbH - Hainhäuser Weg 93 - 30855 Langenhagen - Germany - www.inter-tech.de...
