DuraMax 8 Ft WoodSide Owner's Manual

Size 8 ft x 6 ft / 2.4 m x 1.6 m
Hide thumbs

Advertisement

Quick Links

Download this manual
A L L
P U R P O S E
V I N Y L
G A R D E N
Vinyl Garden Shed
Vinyl Garden Shed
OWNER'S MANUAL /
Instructions for Assembly '8 Ft WoodSide'
Size 8 Ft x 6 Ft / 2.4 m x 1.6 m
Ver: 0.0
Your Total Solution To Maintenance Free Storage Sheds.
• All Weather Durable PVC
• Won't Dent, Rust, Rot or Mildew
• Tall Walk In Shed
• Never Needs Painting
• 61 Inch Wide Double Doors
• Easy Assembly
• High Wind Tested
• Snow Load Tested 20lbs/sq. foot
• Pad Lock Ready (Lock not included)
• Wooden or Cement Foundation Needed
Available Kits
• Foundation Kit Available
• Modular 2.5 Ft Extension Kits Available
• 8 Ft x 6 Ft Window Kits Available
Approximate
Size
Area
8 Ft x 6 Ft
39 Sq. Ft
3.6 Sq. m
2.4 m x 1.6 m
TM
A Product of
S H E D S
Building Dimensions :
Storage
Volume
Base Dimension
238 1/4 Cu. Ft
Width
Depth
6.8 Cu. m
Height
(Approx.)
Requires two people and takes about
3-4 hours for Installation.
Exterior Dimension
Roof Edge to Edge
inch
cm
inch
94 1/4
239.4
94 3/8
160.3
63 1/8
64
77 1/4
Customer
Service Hotline
(800) 483-4674
www.uspolymersinc.com
Call us for any missing or damaged parts.
Do not return to the store.
Interior Dimension
Wall to Wall
cm
inch
cm
239.7
92 1/4
234.3
162.5
155.2
61 1/8
73
185.5
196.2
Door Opening
inch
cm
154
60 5/8
71 1/2
181.6
