Summary of Contents for CIG WF-180
- Page 1 WF-180 Wireless Access Point...
-
Page 2: Package List
1. Introduction WF-180 is a dual-band 2x2streams and chains indoor Wi-Fi AP, which is complied with the IEEE802.11n standard and designed for high-density deployments in offices, schools, hospitals and hotels that require premium performance. -
Page 3: Installation
Console port Also names as RJ-11, used to manage WF-180 software. Reset button Pressing the button longer than 5s to restore the device to factory defaults and reset the device. DC power connector used for connecting the power adapter USB port supports a USB 2.0 connector(Support up to 0.5A) - Page 4 Installation tool: • Screws and screw-driver Installation site: Please ensure the visibility of product and no tall buildings and woods block between them. Installation procedure Wall mounting Drive two screws fist in the wall. The distantbetween two screws mounted on the wall is 40mm.
- Page 5 Align the securing hookof AP with bracket, and push AP from up to down until it has been locked fully. Ceiling mounting: Fasten ceiling rails by pushing bracket as the indicated direction Secure the screw to fasten bracket assembly.
- Page 6 2.3. Align securing hookof AP with bracket (see dotted line), and then push AP close to bracket until AP has been fully Locked...
-
Page 7: Led Definition
3.4. Go through locking holes by cable-tie to safely content AP with bracket 5. LED Definition Function State-Color Indication AP power / ready status Steady - Green APis ready Flashing - Green AP is managed by controller AP hardware failure No power to AP Network Link Status Steady - Green... -
Page 8: Product Specification
Input the default IP address 192.168.188.251 in the address bar of the web browser and press Enter. Enter username and password (username: admin, password: password), after password authentication is successful, the web page is displayed. 7. Product Specification Physical specification Dimensions 160 mm x 160 mm x 40mm(Width x Length x Height) Weight... - Page 9 Specially, restricted materials are Lead, Cadmium, Mercury, Hexavalent Chromium, and Bromine. CIG products comply with this requirement and all marked with “RoHS” shown at the left. China RoHS WF-180 AP complies with China environmental declaration requirements and is labeled with “EFUP 20”...
-
Page 10: Safety And Regulatory Compliance
对销售之日的所售产品，本表显示剑桥公司供应链的电子信息产品可能包含这些物质。注意：在所售产 品中可能会也可能不会含有所有所列的部件。 This table shows where these substances may be found in the supply chain of CIG electronic information products, as of the date of sale of the enclosed product. Note that some of the component types listed above may or may not be a part of the enclosed product. -
Page 11: Technical Support
LAN/POE port is correct. 12.11. Technical Support CIG offers technical support 24 hours a day, 7 days a week. Use one of the following methods to contact CIG technical assistance center: Hotline: +86 21 6192 1930 Email: support@cambridgeig.com... -
Page 12: Legal Declaration
CIG name, CIG logo, and all CIG product names are trademarks of Cambridge Industries Group Co. Ltd (CIG). All other brand and product names are claimed as property of others respective holders. Specifications, products, and products names are subject to change without notice. - Page 13 Federal Communications Commission (FCC) Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 14 IC Radiation Exposure Statement for Canada This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
- Page 15 forth for an uncontrolled environment”. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.
